AC Fans

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Material	Housing Material	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Termination	Max Operating Temperature	Min Operating Temperature	Depth	Operating Supply Voltage	Diameter	Length	RoHS Status	Lead Free	Voltage - Rated	Current Rating	Radiation Hardening	Package / Case	Reach Compliance Code	Frequency	Height	Width	Approval Agency	Thickness	Weight	Operating Temperature	Size / Dimension	Voltage Range	Ratings	Ingress Protection	Power Rating	Max Power Dissipation	Feature	Current Rating (Amps)	Lifetime @ Temp	Life (Hours)	Air Flow	Power (Watts)	Material - Frame	Material - Blade	RPM	Bearing Type	Fan Type	Noise	Static Pressure	Thermal Support Device Type
55442.40765	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks	Flanges					QLK45	Active	1 (Unlimited)	Terminal Block							RoHS Compliant	Lead Free	240VAC					5.06kHz			CSA, UL, VDE				Rectangular - 265mm Lx71mm H 45mm Dia				28W	28W					75.0 CFM (2.10m3/min)	28.00W	Steel	Aluminum		Sleeve	Blower, Cross Flow	50.0 dB(A)		AC BLOWER
17000539A	Comair Rotron	RFQ Min: 1 Mult: 1	download	18 Weeks					2016		Active	Not Applicable	2 Terminals							ROHS3 Compliant		100V~240VAC							38.00mm	CE, cUL, UL		0.816lb 370.13g	-4~158°F -20°C~70°C	Square - 120mm Lx120mm H	90V~264VAC					Auto Restart, Electronic Commutation (EC)	0.180A	Varies Based on Temperature		130.0 CFM (3.64m3/min)	10.00W	Magnesium Alloy	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	4000 RPM	Ball	Tubeaxial	56.0 dB(A)	0.430 in H2O (107.0 Pa)
109S093	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1	download	16 Weeks			Aluminium			San Ace 92	Active	Not Applicable	2 Terminals				115V			ROHS3 Compliant		115VAC				unknown				CE, CSA, PSE, TUV, UL		0.639lb 289.85g	-22~140°F -30°C~60°C	Square - 92mm Lx92mm H				7W			0.080A	25000 Hrs @ 60°C		38.9 CFM (1.09m3/min)	7.00W	Aluminum	Plastic	3100 RPM	Ball	Tubeaxial	38.0 dB(A)	0.197 in H2O (49.0 Pa)	AC FAN
LPH12A99-BTHR-2EM-EX	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	14 Weeks						LPH12A99	Active	1 (Unlimited)	2 Terminals							RoHS Compliant		100V~240VAC								ATEX		0.631lb 286.20g		Square - 120mm Lx120mm H	90V~264VAC		IP68 - Dust Tight, Waterproof			Auto Restart, Electronic Commutation (EC)	0.180A			123.9 CFM (3.47m3/min)	9.50W	Plastic		3500 RPM	Ball	Tubeaxial	49.0 dB(A)	0.363 in H2O (90.5 Pa)
OA172SAP-11-1TB1855	Orion Fans	RFQ Min: 1 Mult: 1	download	17 Weeks			Aluminium		2013	OA172SAP	Active	1 (Unlimited)	2 Terminals							ROHS3 Compliant		115VAC						150mm		cURus		2.7lbs 1.2kg	-22~176°F -30°C~80°C	Rectangular/Rounded - 172mm Lx150mm H	100V~120VAC	IP55, Water Resistant	IP55 - Dust Protected, Water Resistant	35W	42W			50000 Hrs @ 55°C	50000 hours	210.0 CFM (5.88m3/min)	42.00W	Aluminum	Metal	3100 RPM	Ball	Tubeaxial	58.0 dB(A)	0.490 in H2O (122.1 Pa)
55462.19750	ebm-papst Inc.	RFQ Min: 1 Mult: 1		20 Weeks						55462	Active	Not Applicable								RoHS Compliant		240VAC							60.00mm																38.00W				Sleeve	Blower
UF250APA23-H1C2A	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2007	UF250APA	Active	1 (Unlimited)	2 Wire Leads							RoHS Compliant		230VAC							98.00mm	CE, cUL, TUV, UL		6.8lbs 3.1kg	-40~122°F -40°C~50°C	Round - 251mm Dia						Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)	1.00A			850.0 CFM (23.80m3/min)	240W	Aluminum	Polyamide (PA), Nylon	2700 RPM	Ball	Motorized Impellers	76.0 dB(A)	2.900 in H2O (722.4 Pa)
A6D630-AN01-01	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks	Screw					A6D630	Active	Not Applicable	Terminal Block							RoHS Compliant		480VAC								CCC, CE, EAC, VDE			-40~131°F -40°C~55°C	Round - 630mm Dia			IP54 - Dust Protected, Water Resistant			Thermal Overload Protector (TOP)	0.800A			4426.3 CFM (123.94m3/min)	550W		Steel	1010 RPM	Ball	Tubeaxial, 3 Phase		0.140 in H2O (34.9 Pa)
7F.21.8.230.3100	Finder Relays, Inc.	RFQ Min: 1 Mult: 1								7F	Active		2 Terminals									230VAC								CE, cULus, cURus, EAC			5~131°F -15°C~55°C	Square - 209mm Lx209mm H	184V~253VAC		IP54 - Dust Protected, Water Resistant			Exhaust Filter	0.120A	50000 Hrs @ 40°C		59.0 CFM (1.65m3/min)	28.00W	Plastic			Ball	Tubeaxial	42.0 dB(A)
4715FS-23T-B5A-D00	NMB Technologies Corporation	RFQ Min: 1 Mult: 1	download	18 Weeks					2002	FS	Active	1 (Unlimited)	2 Terminals							RoHS Compliant	Lead Free	230VAC	80mA		Axial					CE, CSA, TUV, UL		1.2lbs 544.3g	14~158°F -10°C~70°C	Square - 119mm Lx119mm H					14W		0.080A			110.0 CFM (3.08m3/min)	14.00W	Aluminum	Plastic	3100 RPM	Ball	Tubeaxial	45.0 dB	0.370 in H2O (92.2 Pa)
R87FA3A85HP	Omron Electronics Inc-EMC Div	RFQ Min: 1 Mult: 1		60 Weeks						R87F	Active	1 (Unlimited)								RoHS Compliant		115VAC								CSA, UL											0.097A			32.1 CFM (0.899m3/min)	8.00W			3250 RPM	Ball	Tubeaxial	43.0 dB
ASEN60512	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1	download						2006		Obsolete	1 (Unlimited)	2 Wire Leads									115VAC											14~140°F -10°C~60°C	Square - 60mm Lx60mm H							0.060A			9.3 CFM (0.260m3/min)	4.00W	Aluminum	Plastic	2600 RPM	Ball	Tubeaxial	29.0 dB(A)
109-603	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1	download	16 Weeks			Aluminium	Bulk	2016	San Ace 160	Active	Not Applicable	2 Terminals				230V		160mm	ROHS3 Compliant		230VAC						160mm	51.00mm	CE, CSA, PSE, TUV, UL		2.4lbs 1.1kg	-22~140°F -30°C~60°C	Square - 160mm Lx160mm H				33W			0.160A	25000 Hrs @ 60°C		300.4 CFM (8.41m3/min)	33.00W	Aluminum	Plastic	3350 RPM	Ball	Tubeaxial	60.0 dB(A)	0.669 in H2O (166.6 Pa)
109-373	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1								San Ace 172	Active	Not Applicable	3 Wire Leads							ROHS3 Compliant		230VAC								CE, PSE, TUV, UL		2.3lbs 1kg	14~140°F -10°C~60°C	Round - 172mm Dia						Alarm	0.270A			226.1 CFM (6.33m3/min)	25.00W	Aluminum	Plastic	3350 RPM		Tubeaxial	51.0 dB(A)	0.787 in H2O (196.0 Pa)
4715MS-22T-B10-B00	NMB Technologies Corporation	RFQ Min: 1 Mult: 1	download	18 Weeks			Aluminium		2004	MS	Active	1 (Unlimited)	2 Terminals			119mm				RoHS Compliant	Lead Free	220VAC	40mA	No	Axial			38mm		CE, CSA, TUV, UL, VDE		1.2lbs 544.3g	14~158°F -10°C~70°C	Square - 119mm Lx119mm H					5.5W		0.040A	50000 Hrs @ 25°C		49.4 CFM (1.38m3/min)	5.50W	Aluminum	Polycarbonate (PC), Fiberglass Reinforced	1450 RPM	Ball	Tubeaxial	28.0 dB	0.059 in H2O (14.7 Pa)
UF220APA12-H2C2A-B1	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2014	UF220APA	Active	1 (Unlimited)	3 Wire Leads							RoHS Compliant		115VAC							71.00mm	CE, cUL, TUV, UL		3.2lbs 1.5kg	-40~122°F -40°C~50°C	Round - 223mm Dia						Permanent Split Capacitor Motor, Speed Sensor (Tach), Thermal Overload Protector (TOP)	0.800A			530.0 CFM (14.84m3/min)	117W	Aluminum	Polyamide (PA), Nylon	2650 RPM	Ball	Motorized Impellers	70.0 dB(A)	1.700 in H2O (423.5 Pa)
OA109AP-11-1TBR	Orion Fans	RFQ Min: 1 Mult: 1	download	15 Weeks	Flanges		Aluminium		2009	OA109	Active	1 (Unlimited)	2 Terminals				115V			ROHS3 Compliant		115VAC			Axial		5.06kHz	119.5mm		cURus, TUV	38mm		-4~176°F -20°C~80°C	Square - 119.5mm Lx119.5mm H	80V~130VAC			15W	15W	Reverse Air Flow		60000 Hrs @ 40°C	60000 hours	99.0 CFM (2.77m3/min)	15.00W	Aluminum	Polybutylene Terephthalate (PBT)	3100 RPM	Ball	Tubeaxial	47.0 dB	0.330 in H2O (82.2 Pa)
4715TS-20T-B50-BM0	NMB Technologies Corporation	RFQ Min: 1 Mult: 1	download	18 Weeks			Aluminium		2009	TS	Active	1 (Unlimited)	2 Terminals			119mm				RoHS Compliant		200VAC	170mA	No	Axial			38mm		CE, UL, VDE		1.4lbs 635g	14~140°F -10°C~60°C	Square - 119mm Lx119mm H					17W		0.170A	50000 Hrs @ 25°C		116.5 CFM (3.26m3/min)	17.00W	Aluminum	Steel	3100 RPM	Ball	Tubeaxial	50.0 dB	0.400 in H2O (99.6 Pa)
4715MS-20T-B40-B00	NMB Technologies Corporation	RFQ Min: 1 Mult: 1	download	18 Weeks			Aluminium		2004	MS	Active	1 (Unlimited)	2 Terminals			119mm				RoHS Compliant		200VAC	110mA	No	Axial			38mm		CE, CSA, TUV, UL, VDE		1.2lbs 544.3g	14~158°F -10°C~70°C	Square - 119mm Lx119mm H					13W		0.110A	50000 Hrs @ 25°C		95.0 CFM (2.66m3/min)	13.00W	Aluminum	Polycarbonate (PC), Fiberglass Reinforced	2750 RPM	Ball	Tubeaxial	39.0 dB	0.255 in H2O (63.7 Pa)
AFF-5010B-120VAC	Altech Corporation	RFQ Min: 1 Mult: 1		3 Weeks					2013		Active	1 (Unlimited)								ROHS3 Compliant
R2E250-AU51-05	ebm-papst Inc.	RFQ Min: 1 Mult: 1		8 Weeks						R2E250	Active	Not Applicable								RoHS Compliant														Round - 250mm Dia						Capacitor, Thermal Overload Protector (TOP)									Ball	Motorized Impellers
R87T-A3A15HP	Omron Electronics Inc-EMC Div	RFQ Min: 1 Mult: 1	download	10 Weeks	Flanges		Aluminium		2008	R87T	Active	1 (Unlimited)	2 Terminals							RoHS Compliant		115VAC	190mA		Axial	unknown	5.06kHz	38mm		CSA, UL		1.3lbs 589.7g	-4~158°F -20°C~70°C	Square - 120mm Lx120mm H				2.018kW	18W		0.190A			107.1 CFM (3.00m3/min)	18.00W	Aluminum	Zinc	3100 RPM	Ball	Tubeaxial	46.0 dB	0.236 in H2O (58.8 Pa)	AC FAN
ASEN10211	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1							2006		Obsolete	1 (Unlimited)	2 Wire Leads	140°C	14°C					RoHS Compliant		100VAC	180mA						25.50mm			0.794lb 360.15g	14~140°F -10°C~60°C	Square - 119mm Lx119mm H					11W		0.180A			70.6 CFM (1.98m3/min)	11.00W	Aluminum	Plastic	2700 RPM	Ball	Tubeaxial	38.0 dB(A)
G2D146-BF04-24	ebm-papst Inc.	RFQ Min: 1 Mult: 1								G2D146	Active	Not Applicable	Terminal Block							RoHS Compliant		230/380/460VAC								CE, UL			-13~140°F -25°C~60°C	Rectangular/Rounded - 227mm Lx248.5mm H	220V~380VAC		IP20				0.360A				225W 280W 310W	Aluminum	Steel	2400/2700 RPM	Ball	Blower, Centrifugal		0.803 in H2O (200.0 Pa)
R87T-A1A15H-WR	Omron Electronics Inc-EMC Div	RFQ Min: 1 Mult: 1	download	7 Weeks	Flanges		Aluminium		2008	R87T	Active	1 (Unlimited)	2 Wire Leads							RoHS Compliant		100VAC	280mA		Axial	unknown	5.06kHz	119.5mm		CSA, UL		1.4lbs 635g	-4~158°F -20°C~70°C	Square - 119.5mm Lx119.5mm H	85V~110VAC			2.22kW	20W		0.280A			114.3 CFM (3.20m3/min)	20.00W	Aluminum	Zinc	2900 RPM	Ball	Tubeaxial	46.0 dB	0.321 in H2O (80.0 Pa)	AC FAN
W2E250-CM06-01	ebm-papst Inc.	RFQ Min: 1 Mult: 1		8 Weeks	Flanges	Steel		Bulk		W2E250	Active	Not Applicable	4 Wire Leads with Splice Terminals					320mm		RoHS Compliant		230VAC		No	Axial		5.06kHz	96mm		CE, EAC			-13~122°F -25°C~50°C	Round - 320mm Dia			IP44	115.15kW		Capacitor, Thermal Overload Protector (TOP)	0.660A				150W			2600 RPM	Ball	Tubeaxial		0.341 in H2O (85.0 Pa)
UF15PC23-BWHNR	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2015	UF15PC	Active	Not Applicable	2 Wire Leads							RoHS Compliant		230VAC								CE, cUL, TUV, UL		1.8lbs 816.5g	-40~158°F -40°C~70°C	Rectangular/Rounded - 172mm Lx150mm H			IP55 - Dust Protected, Water Resistant			Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)	0.120A			226.0 CFM (6.33m3/min)	29.00W	Aluminum	Polybutylene Terephthalate (PBT)	3400 RPM	Ball	Tubeaxial	58.0 dB(A)	0.790 in H2O (196.8 Pa)
UF300BNA12-H1C2A	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2014	UF300BNA	Active	1 (Unlimited)	2 Wire Leads							RoHS Compliant		115VAC							98.30mm	CE, cUL, TUV, UL		9.9lbs 4.5kg	-4~158°F -20°C~70°C	Round - 398mm Dia						Permanent Split Capacitor Motor	2.40A			1615.0 CFM (45.22m3/min)	200W	Steel	Steel	2950 RPM	Ball	Tubeaxial	78.0 dB(A)	1.100 in H2O (274.0 Pa)
QK10A-4/110756	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download		Flanges					QK10A	Obsolete	1 (Unlimited)	Terminal Block			200mm				RoHS Compliant	Lead Free	230VAC		No				175mm				10lbs 4.5kg		Rectangular - 488mm Lx175mm H 92mm Dia				85W	85W					410.0 CFM (11.48m3/min)	85.0W	Steel	Aluminum		Ball	Blower, Cross Flow	68.0 dB(A)
OA80AP-11-3WB	Orion Fans	RFQ Min: 1 Mult: 1	download	15 Weeks			Aluminium		2010	OA80	Active	1 (Unlimited)	2 Wire Leads							ROHS3 Compliant		115VAC	100mA		Axial		833MHz	80mm		cURus, TUV	38mm		-4~176°F -20°C~80°C	Square - 80mm Lx80mm H	103V~126VAC			5W	9W		0.100A	60000 Hrs @ 40°C		17.0 CFM (0.476m3/min)	9.00W	Aluminum	Polybutylene Terephthalate (PBT)	1950 RPM	Ball	Tubeaxial	28.0 dB	0.070 in H2O (17.4 Pa)
