Heat Sinks

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Diameter	Length	RoHS Status	Lead Free	Contact Plating	Radiation Hardening	Package / Case	REACH SVHC	Height	Width	Weight	Manufacturer Package Identifier	Type	Body Material	Power Dissipation	Natural Thermal Resistance	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise
322400B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	11 Weeks	Press Fit	Aluminum	Cylindrical	Bulk	2007		Active	Not Applicable	Black		0.180 4.57mm ID 0.500 12.70mm OD	12.7mm	RoHS Compliant	Lead Free		No	TO-18	Unknown	6mm	12.7mm			Top Mount				100.00°C/W	0.235 5.97mm	Press Fit	TO-18	30.00°C/W @ 500 LFM	Black Anodized	0.6W @ 60°C
529801B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2001		Active	Not Applicable	Black	25.4mm		1.500 38.10mm	RoHS Compliant	Lead Free		No	Radial	No SVHC	38mm	1.650 41.91mm		529801b02500g	Board Level, Vertical				5.00°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-218	2.00°C/W @ 500 LFM	Black Anodized	10.0W @ 50°C
7020B-MTG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Through Hole	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	11.94mm		1.450 36.83mm	RoHS Compliant	Lead Free		No	TO-2	No SVHC	35.83mm	1.300 33.02mm	113.398093g	7020B-MTG	Board Level, Vertical				8.70°C/W	0.470 11.94mm	Bolt On and PC Pin	TO-220	3.00°C/W @ 800 LFM	Black Anodized	8.0W @ 70°C
701652F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Fins		2016		Active	Not Applicable				48.000 1219.20mm	RoHS Compliant							12.000 304.80mm			Top Mount, Extrusion					1.780 45.21mm	Adhesive		0.20°C/W @ 700 LFM
574802B03700G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Clip, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	10.67mm		0.900 22.86mm	RoHS Compliant				TO-220		22.86mm	1.020 25.91mm			Board Level, Vertical				20.40°C/W	0.420 10.67mm	Clip and PC Pin	TO-220	6.00°C/W @ 500 LFM	Black Anodized	3.0W @ 60°C
607602F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				48.000 1219.20mm	RoHS Compliant							3.250 82.55mm			Top Mount, Extrusion					1.000 25.40mm	Adhesive				4.0W @ 20°C
322605B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical	Bulk	2007		Active	Not Applicable	Black		0.315 8.00mm ID 0.750 19.05mm OD	19.05mm	RoHS Compliant	Lead Free		No	TO-5	No SVHC	6mm				Top Mount		1.25W		54.00°C/W	0.250 6.35mm	Press Fit	TO-5	25.00°C/W @ 200 LFM	Black Anodized	1.0W @ 60°C
584000B03300G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks					2007	5840	Active	Not Applicable					RoHS Compliant																			Black Anodized
593202B03400G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			2.000 50.80mm	RoHS Compliant				TO-220		50.8mm	1.380 35.05mm			Board Level, Vertical				10.40°C/W	0.480 12.19mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 200 LFM	Black Anodized	6.0W @ 60°C
568003B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1		8 Weeks		Aluminum	Square				Active	Not Applicable				1.810 45.97mm	RoHS Compliant							1.810 45.97mm			Board Level				8.00°C/W	0.500 12.70mm	Bolt On	TO-3	1.50°C/W @ 400 LFM	Black Anodized	5.0W @ 50°C
6263B-MT5G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Box	2007		Active	Not Applicable		10.16mm		1.750 44.45mm	RoHS Compliant	Lead Free			TO-218			1.760 44.70mm			Board Level, Vertical				8.80°C/W	0.400 10.16mm	Bolt On and PC Pin	TO-220, TO-218	6.00°C/W @ 400 LFM	Black Anodized	6.0W @ 60°C
7178DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Bolt, PC Pin, Screw	Copper	Rectangular, Fins		2007		Active	Not Applicable		9.52mm		0.750 19.05mm	RoHS Compliant	Lead Free			TO-220		19.05mm	0.520 13.21mm			Board Level, Vertical	Copper			35.70°C/W	0.375 9.52mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 700 LFM	Tin	0.6W @ 30°C
6381BG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.500 38.10mm	RoHS Compliant				TO-218		38.1mm	1.650 41.91mm			Board Level, Vertical				5.80°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220, TO-218	3.50°C/W @ 200 LFM	Black Anodized	6.0W @ 50°C
576802B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, Plug-In	Aluminum	Rectangular, Fins	Bulk	2003		Active	Not Applicable	Black	12.7mm		0.750 19.05mm	RoHS Compliant	Lead Free		No	TO-220	No SVHC	12.7mm	0.500 12.70mm			Board Level				27.30°C/W	0.500 12.70mm	Clip	TO-220, TO-262	7.00°C/W @ 400 LFM	Black Anodized	1.5W @ 40°C
782653B01000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks					2007		Active	Not Applicable					RoHS Compliant				TO-220
531102B02100G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	12.7mm		1.500 38.10mm	RoHS Compliant	Lead Free	Tin		Radial	No SVHC	38.1mm	1.374 34.90mm			Board Level, Vertical				10.40°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 300 LFM	Black Anodized	7.0W @ 70°C
534202B03453G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	12.7mm		1.180 29.97mm	RoHS Compliant	Lead Free		No	TO-220	No SVHC	29.97mm	1.000 25.40mm			Board Level, Vertical				13.40°C/W	0.500 12.70mm	Clip and Board Locks	TO-220	6.00°C/W @ 300 LFM	Black Anodized	1.0W @ 20°C
622851F00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminium			2007		Active	1 (Unlimited)				2.4384m	RoHS Compliant						41.4mm	171.45mm						0.22 °C/W
531202B02500G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	12.7mm		2.000 50.80mm	RoHS Compliant	Lead Free		No	TO-220	No SVHC	50.8mm	1.375 34.93mm			Board Level, Vertical				7.50°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220, TO-202	4.00°C/W @ 600 LFM	Black Anodized	5.0W @ 40°C
576802B03300G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.748 19.00mm	RoHS Compliant	Lead Free			TO-220		19.05mm	0.500 12.70mm			Board Level, Vertical				27.30°C/W	0.500 12.70mm	Clip and PC Pin	TO-220, TO-262	7.00°C/W @ 400 LFM	Black Anodized	1.0W @ 30°C
322505B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical	Bulk	2007		Active	Not Applicable	Black	19.05mm	0.315 8.00mm ID 0.750 19.05mm OD	19.05mm	RoHS Compliant	Lead Free	Tin	No	TO-5	Unknown	10.16mm	19.05mm			Top Mount				56.00°C/W	0.400 10.16mm	Press Fit	TO-5	15.00°C/W @ 400 LFM	Black Anodized	0.5W @ 30°C
622002F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				48.000 1219.20mm	RoHS Compliant							3.500 88.90mm			Top Mount, Extrusion					0.850 21.60mm	Adhesive		1.50°C/W @ 200 LFM
780802F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				49.500 1257.30mm	RoHS Compliant							1.063 27.00mm			Board Level, Vertical, Extrusion					2.362 60.00mm	PC Pin
513101B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt	Aluminum	Rectangular, Fins		2007		Active	Not Applicable				1.500 38.10mm	Non-RoHS Compliant							1.380 35.05mm			Board Level				11.00°C/W	0.500 12.70mm	Bolt On	TO-218	3.00°C/W @ 500 LFM	Black Anodized	8.0W @ 80°C
7129DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Clip	Copper	Rectangular, Fins		2007		Active	Not Applicable				1.040 26.42mm	RoHS Compliant				TO-220		26.42mm	0.866 22.00mm			Board Level				19.20°C/W	0.375 9.52mm	Clip	TO-220	7.00°C/W @ 500 LFM	Tin	3.5W @ 70°C
577002B04000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	6.35mm		0.750 19.05mm	RoHS Compliant	Lead Free		No	TO-220	No SVHC	19.05mm	0.520 13.21mm	113.398093g		Board Level, Vertical				32.00°C/W	0.250 6.35mm	Bolt On and PC Pin	TO-220	16.00°C/W @ 200 LFM	Black Anodized	1.5W @ 50°C
7106DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Surface Mount	Copper	Rectangular, Fins	Box	2007		Active	Not Applicable		14.99mm		0.590 15.00mm	RoHS Compliant	Lead Free	Tin	No	TO-263	No SVHC	10mm	1.020 25.91mm			Top Mount			15 °C/W		0.375 9.52mm	SMD Pad	TO-263 (D2Pak), PowerSO-10 (MO-184), SO-10	5.00°C/W @ 400 LFM	Tin	2.0W @ 40°C
531002B02100G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.000 25.40mm	RoHS Compliant				Radial		25.94mm	1.375 34.93mm			Board Level, Vertical				13.40°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 400 LFM	Black Anodized	2.0W @ 30°C
7130DG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Clip, PC Pin	Copper	Rectangular, Fins		2007		Active	Not Applicable		15.49mm		1.025 26.04mm	RoHS Compliant	Lead Free			TO-218		15.49mm	1.005 25.53mm			Board Level, Vertical	Copper			23.10°C/W	0.610 15.49mm	Clip and PC Pin	TO-218	4.00°C/W @ 500 LFM	Tin	0.5W @ 20°C
7024B-MTG	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	19.05mm		1.620 41.15mm	RoHS Compliant	Lead Free		No	TO-2	No SVHC	41mm	2.000 50.80mm	113.398093g		Board Level, Vertical				5.60°C/W	0.750 19.05mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 200 LFM	Black Anodized	9.0W @ 60°C
