Name	Manufacturer	Pricing(USD)	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Diameter	Length	RoHS Status	Lead Free	Contact Plating	Radiation Hardening	Package / Case	REACH SVHC	Height	Width	Weight	Type	Body Material	Power Dissipation	Natural Thermal Resistance	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise
7025B-MTG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Box	2007		Active	Not Applicable	Black	24.13mm		1.130 28.70mm	RoHS Compliant	Lead Free		No	TO-220	No SVHC	29mm	1.900 48.26mm	113.398093g	Board Level, Vertical				6.80°C/W	0.950 24.13mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 300 LFM	Black Anodized	6.0W @ 50°C
533201B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable				2.000 50.80mm	RoHS Compliant							1.375 34.93mm		Board Level, Vertical				9.00°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-218, TO-247	3.00°C/W @ 400 LFM	Black Anodized	3.0W @ 30°C
780752F00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				49.500 1257.30mm	RoHS Compliant							1.496 38.00mm		Board Level, Vertical, Extrusion					2.126 54.00mm	PC Pin
627252F00000	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Fins				Active	Not Applicable				55.500 1409.70mm	RoHS Compliant							9.750 247.65mm		Top Mount, Extrusion					2.280 57.91mm	Adhesive		0.20°C/W @ 700 LFM
573100D00010G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	PCB, Surface Mount	Aluminum	Rectangular, Fins	Cut Tape (CT)	2007	5731	Active	1 (Unlimited)		8mm		0.315 8.00mm	RoHS Compliant	Lead Free		No	DPAK	No SVHC	10mm	0.900 22.86mm		Top Mount				26.00°C/W	0.400 10.16mm	SMD Pad	TO-252 (DPak)	12.50°C/W @ 600 LFM	Tin	0.8W @ 30°C
530001B00000	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt	Aluminum	Rectangular, Fins		2007		Active	Not Applicable				2.500 63.50mm	Non-RoHS Compliant							1.650 41.91mm		Board Level				3.80°C/W	1.000 25.40mm	Bolt On	TO-218	2.50°C/W @ 200 LFM	Black Anodized	16.0W @ 50°C
533602B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable				2.500 63.50mm	RoHS Compliant							1.650 41.91mm		Board Level, Vertical				3.80°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220	2.00°C/W @ 300 LFM	Black Anodized	16.0W @ 50°C
574204B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular	Bulk	2007		Active	Not Applicable	Black			0.900 22.86mm	RoHS Compliant	Lead Free			TO-202		22.86mm	1.020 25.91mm		Board Level				16.80°C/W	0.420 10.67mm	Clip	TO-202	8.00°C/W @ 200 LFM	Black Anodized	1.0W @ 20°C
550202D00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin		Rectangular		2007		Active	Not Applicable				1.675 42.55mm	RoHS Compliant							1.000 25.40mm		Board Level, Vertical				12.40°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220	3.00°C/W @ 700 LFM	Tin	1.5W @ 20°C
341900F00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1		9 Weeks	Adhesive	Copper			2009		Active	Not Applicable	Black	25.4mm		76.2mm	RoHS Compliant		Tin	No	BGA		330μm	25.4mm		Passive	Copper
371824B00032G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	8 Weeks	Surface Mount	Aluminum	Square, Pin Fins	Bulk	2002		Active	Not Applicable	Black	35mm		1.378 35.00mm	RoHS Compliant	Lead Free		No	BGA	No SVHC	7mm	1.378 35.00mm		Top Mount				31.90°C/W	0.275 7.00mm	Thermal Tape, Adhesive (Included)	BGA	9.70°C/W @ 200 LFM	Black Anodized	1.5W @ 50°C
531102B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	12.7mm		1.500 38.10mm	RoHS Compliant	Lead Free		No	Radial	No SVHC	12.7mm	1.375 34.93mm		Board Level, Vertical				10.40°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	3.00°C/W @ 500 LFM	Black Anodized	7.0W @ 70°C
6232B-MTG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2006		Active	Not Applicable		13mm		1.774 45.06mm	RoHS Compliant	Lead Free			TO-220			1.378 35.00mm		Board Level, Vertical				10.00°C/W	0.512 13.00mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 400 LFM	Black Anodized	3.0W @ 40°C
7038BG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	9.65mm		0.620 15.75mm	RoHS Compliant	Lead Free			SIP		15.75mm	0.915 23.24mm		Board Level				16.00°C/W	0.380 9.65mm	Clip	Multiwatt, SIP	6.00°C/W @ 600 LFM	Black Anodized	1.5W @ 40°C
574802B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.900 22.86mm	RoHS Compliant				TO-220		22.86mm	1.020 25.91mm		Board Level				20.40°C/W	0.420 10.67mm	Clip	TO-220	6.00°C/W @ 500 LFM	Black Anodized	3.0W @ 60°C
342943	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	6 Weeks	Push Pin	Copper	Square, Fins				Active	Not Applicable				1.969 50.00mm	RoHS Compliant							1.969 50.00mm		Top Mount				8.90°C/W	0.551 14.00mm	Push Pin	BGA	2.10°C/W @ 200 LFM	AavSHIELD 3C
780102F00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				49.500 1257.30mm	RoHS Compliant							1.339 34.00mm		Board Level, Vertical, Extrusion					2.953 75.00mm	PC Pin
581002B00000	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rectangular, Fins		1999		Active	Not Applicable	Black	16.256mm		1.000 25.40mm	RoHS Compliant	Lead Free			TO-220			0.640 16.26mm		Board Level		4.3W			0.640 16.26mm	Bolt On	TO-220	4.00°C/W @ 500 LFM	Black Anodized	2.5W @ 50°C
645002F00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				48.000 1219.20mm	RoHS Compliant							5.900 149.86mm		Top Mount, Extrusion					1.063 27.00mm	Adhesive		0.50°C/W @ 500 LFM
576602D00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable		12.7mm		0.950 24.13mm	RoHS Compliant	Lead Free			TO-220		24.13mm	1.000 25.40mm		Board Level, Vertical				16.60°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	9.00°C/W @ 200 LFM	Tin	4.0W @ 70°C
HF20G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	20mm		0.790 20.07mm	RoHS Compliant	Lead Free		No	TO-220		28mm	1.102 28.00mm		Board Level, Vertical				13.10°C/W	0.787 19.99mm	Clip and PC Pin	TO-220	6.00°C/W @ 400 LFM	Black Anodized	1.0W @ 20°C
2333BG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1		9 Weeks							Active	Not Applicable					RoHS Compliant
576012B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.900 22.86mm	RoHS Compliant	Lead Free			TO-220		9.65mm	1.000 25.40mm		Board Level				20.80°C/W	0.380 9.65mm	Bolt On	TO-220	4.00°C/W @ 700 LFM	Black Anodized	2.0W @ 40°C
523002B00000G	Aavid, Thermal Division of Boyd Corporation	0.5942	Add to Cart Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins	Bulk	2006		Active	Not Applicable	Black	25.4mm		1.180 29.97mm	RoHS Compliant	Lead Free		No	TO-220	No SVHC	29.97mm	1.000 25.40mm	113.398093g	Board Level, Vertical				13.60°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	6.00°C/W @ 300 LFM	Black Anodized	1.0W @ 20°C
579103B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus		2007		Active	Not Applicable	Black	28.57mm	1.125 28.57mm OD	1.540 39.12mm	RoHS Compliant	Lead Free			TO-3	No SVHC	22.1mm	28.57mm		Top Mount				12.50°C/W	0.870 22.10mm	Bolt On	TO-3	4.00°C/W @ 600 LFM	Black Anodized	2.5W @ 40°C
2321BG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks					2007		Active	Not Applicable					RoHS Compliant
374324B60023G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	8 Weeks	Solder	Aluminum	Square, Pin Fins		2002	37432	Active	Not Applicable	Silver	27mm		1.063 27.00mm	RoHS Compliant	Lead Free		No	BGA	No SVHC	10mm	1.063 27.00mm		Board Level				30.60°C/W	0.394 10.00mm	Solder Anchor	BGA, FPGA	6.00°C/W @ 500 LFM	Black Anodized	1.5W @ 50°C
533722B02552G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Anodized			2007		Active	Not Applicable		25.4mm		41.91mm	RoHS Compliant	Lead Free			Radial					Passive			5.7 °C/W
574102B03300G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.750 19.05mm	RoHS Compliant				TO-220		19.05mm	0.860 21.84mm		Board Level, Vertical				23.20°C/W	0.395 10.03mm	Clip and PC Pin	TO-220	8.00°C/W @ 500 LFM	Black Anodized	1.5W @ 40°C
591202B03100G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	15.24mm		0.600 15.24mm	RoHS Compliant				TO-220		12.7mm	0.500 12.70mm		Board Level				26.80°C/W	0.500 12.70mm	Clip and PC Pin	TO-220, TO-262	16.00°C/W @ 200 LFM	Black Anodized	1.0W @ 40°C
