Heat Sinks

Name	Manufacturer	Pricing(USD)	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Length	RoHS Status	Lead Free	Contact Plating	Radiation Hardening	Number of Pins	Package / Case	REACH SVHC	Height	Width	Weight	Type	Body Material	Power Dissipation	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise
530714B05300G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	26.04mm	0.710 18.03mm	RoHS Compliant			No		TO-220		18.03mm	0.955 24.26mm		Board Level			20.30°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 700 LFM	Black Anodized	2.0W @ 40°C
2334BG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks					2007		Active	Not Applicable				RoHS Compliant
592502B02800G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rectangular, Fins		2007		Active	Not Applicable		6.35mm	1.250 31.75mm	RoHS Compliant	Lead Free				TO-220			0.875 22.22mm		Board Level, Vertical			22.00°C/W	0.250 6.35mm	Bolt On and Board Locks	TO-220	10.00°C/W @ 200 LFM	Black Anodized	1.5W @ 40°C
530001B00000	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt	Aluminum	Rectangular, Fins		2007		Active	Not Applicable			2.500 63.50mm	Non-RoHS Compliant								1.650 41.91mm		Board Level			3.80°C/W	1.000 25.40mm	Bolt On	TO-218	2.50°C/W @ 200 LFM	Black Anodized	16.0W @ 50°C
592502B03400G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	6.35mm	1.250 31.75mm	RoHS Compliant	Lead Free	Tin	No		TO-220	No SVHC	31.75mm	0.874 22.20mm		Board Level, Vertical			22.00°C/W	0.250 6.35mm	Bolt On and PC Pin	TO-220	10.00°C/W @ 200 LFM	Black Anodized	1.0W @ 30°C
593002B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rectangular, Fins		2007	Channel 5900	Active	Not Applicable	Black	12.7mm	1.180 29.97mm	RoHS Compliant					TO-220		29.98mm	1.000 25.40mm		Board Level, Vertical			13.40°C/W	0.500 12.70mm	Bolt On	TO-220	4.00°C/W @ 600 LFM	Black Anodized	1.0W @ 20°C
533602B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable			2.500 63.50mm	RoHS Compliant								1.650 41.91mm		Board Level, Vertical			3.80°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220	2.00°C/W @ 300 LFM	Black Anodized	16.0W @ 50°C
530714B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	18.03mm	0.710 18.03mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	18.03mm	1.000 25.40mm	113.398093g	Board Level			20.30°C/W	0.500 12.70mm	Bolt On	TO-220	4.00°C/W @ 700 LFM	Black Anodized	2.0W @ 40°C
501503B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus	Bulk	2003		Active	Not Applicable	Black	35.56mm	1.880 47.75mm	RoHS Compliant	Lead Free		No		TO-3	No SVHC	25.4mm	1.400 35.56mm	113.398093g	Board Level		12W	8.40°C/W	1.000 25.40mm	Bolt On	TO-3	2.00°C/W @ 500 LFM	Black Anodized	5.0W @ 40°C
580200B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Press Fit	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	15.24mm	0.890 22.61mm	RoHS Compliant	Lead Free			14		No SVHC	10mm	0.600 15.24mm		Top Mount			20.00°C/W	0.410 10.42mm	Press Fit, Slide On	14-DIP and 16-DIP	12.00°C/W @ 200 LFM	Black Anodized	1.0W @ 20°C
533201B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable			2.000 50.80mm	RoHS Compliant								1.375 34.93mm		Board Level, Vertical			9.00°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-218, TO-247	3.00°C/W @ 400 LFM	Black Anodized	3.0W @ 30°C
513102B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	34.92mm	1.500 38.10mm	RoHS Compliant	Lead Free		No	24	TO-220	No SVHC	38.1mm	1.375 34.93mm		Board Level, Vertical			11.00°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	3.00°C/W @ 500 LFM	Black Anodized	8.0W @ 80°C
6232B-MTG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2006		Active	Not Applicable		13mm	1.774 45.06mm	RoHS Compliant	Lead Free				TO-220			1.378 35.00mm		Board Level, Vertical			10.00°C/W	0.512 13.00mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 400 LFM	Black Anodized	3.0W @ 40°C
115600F00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1		9 Weeks							Active	Not Applicable				RoHS Compliant
575903B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus		2007		Active	Not Applicable	Black	32.77mm	1.630 41.40mm	RoHS Compliant	Lead Free				TO-3		31.75mm	1.290 32.77mm		Board Level			9.80°C/W	1.250 31.75mm	Bolt On	TO-3	3.00°C/W @ 300 LFM	Black Anodized	7.0W @ 70°C
563002D00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminium	Rectangular, Fins		2007		Active	Not Applicable	Black		1.180 29.97mm	RoHS Compliant	Lead Free				TO-220		29.97mm	1.000 25.40mm		Board Level, Vertical			13.00°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 600 LFM	Tin	1.0W @ 20°C
HF20G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	20mm	0.790 20.07mm	RoHS Compliant	Lead Free		No		TO-220		28mm	1.102 28.00mm		Board Level, Vertical			13.10°C/W	0.787 19.99mm	Clip and PC Pin	TO-220	6.00°C/W @ 400 LFM	Black Anodized	1.0W @ 20°C
591202B03100G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	15.24mm	0.600 15.24mm	RoHS Compliant					TO-220		12.7mm	0.500 12.70mm		Board Level			26.80°C/W	0.500 12.70mm	Clip and PC Pin	TO-220, TO-262	16.00°C/W @ 200 LFM	Black Anodized	1.0W @ 40°C
574102B03300G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black		0.750 19.05mm	RoHS Compliant					TO-220		19.05mm	0.860 21.84mm		Board Level, Vertical			23.20°C/W	0.395 10.03mm	Clip and PC Pin	TO-220	8.00°C/W @ 500 LFM	Black Anodized	1.5W @ 40°C
HF35G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	20mm	1.380 35.05mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	28mm	1.102 28.00mm		Board Level, Vertical			11.10°C/W	0.787 19.99mm	Clip and PC Pin	TO-220	6.00°C/W @ 300 LFM	Black Anodized	2.0W @ 20°C
647061	Aavid, Thermal Division of Boyd Corporation	34.8633	Add to Cart Min: 1 Mult: 1				Copper	Rectangular, Fins				Active	Not Applicable			4.252 108.00mm	RoHS Compliant								3.071 78.00mm		Top Mount				1.004 25.50mm	Bolt On	Intel® Xeon® CPU
6399B-P2G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable		25.4mm	2.000 50.80mm	RoHS Compliant	Lead Free				Radial			1.650 41.91mm		Board Level, Vertical			3.30°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220	1.00°C/W @ 700 LFM	Black Anodized	8.0W @ 40°C
576802B03100G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	14.48mm	0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	12.7mm	0.500 12.70mm		Board Level			27.30°C/W	0.500 12.70mm	Clip and PC Pin	TO-220, TO-262	7.00°C/W @ 400 LFM	Black Anodized	1.0W @ 30°C
533402B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable			1.500 38.10mm	RoHS Compliant								1.650 41.91mm		Board Level, Vertical			5.00°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220	3.00°C/W @ 200 LFM	Black Anodized	10.0W @ 50°C
374324B60023G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	8 Weeks	Solder	Aluminum	Square, Pin Fins		2002	37432	Active	Not Applicable	Silver	27mm	1.063 27.00mm	RoHS Compliant	Lead Free		No		BGA	No SVHC	10mm	1.063 27.00mm		Board Level			30.60°C/W	0.394 10.00mm	Solder Anchor	BGA, FPGA	6.00°C/W @ 500 LFM	Black Anodized	1.5W @ 50°C
529901B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	25.4mm	2.000 50.80mm	RoHS Compliant	Lead Free		No		TO-218	No SVHC	50.8mm	1.650 41.91mm		Board Level, Vertical			4.50°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-218	1.00°C/W @ 800 LFM	Black Anodized	12.0W @ 50°C
504102B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rectangular, Fins	Bulk	2007		Active	Not Applicable	Black	17.8mm	0.701 17.80mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	17.8mm	0.779 19.80mm	113.398093g	Board Level			15.60°C/W	0.850 21.60mm	Bolt On	TO-220	6.00°C/W @ 300 LFM	Black Anodized	2.0W @ 40°C
567103B00000	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download			Aluminum			2007		Active	Not Applicable				Non-RoHS Compliant																TO-3		Black Anodized
574902B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	10.03mm	1.375 34.93mm	RoHS Compliant			No		TO-220		34.93mm	0.860 21.84mm		Board Level			16.00°C/W	0.395 10.03mm	Clip	TO-220	6.00°C/W @ 400 LFM	Black Anodized	2.5W @ 40°C
7128DG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks	Clip, PC Pin	Copper	Rectangular, Fins		2007		Active	Not Applicable		9.52mm	1.100 27.94mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	27.94mm	0.866 22.00mm		Board Level, Vertical	Copper		19.20°C/W	0.375 9.52mm	Clip and PC Pin	TO-220	10.00°C/W @ 200 LFM	Tin	1.5W @ 40°C
