Heat Sinks

Name	Manufacturer	Pricing(USD)	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Diameter	Length	RoHS Status	Lead Free	Radiation Hardening	Number of Pins	Package / Case	REACH SVHC	Height	Width	Weight	Type	Body Material	Hole Diameter	Natural Thermal Resistance	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise
566010B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007	Active	Not Applicable		25.4mm		1.220 30.99mm	RoHS Compliant				SIP			1.000 25.40mm		Board Level				11.50°C/W	0.500 12.70mm	Clip	Multiwatt, SIP	4.00°C/W @ 300 LFM	Black Anodized	3.0W @ 40°C
623352F00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Fins		2016	Active	Not Applicable				36.000 914.40mm	RoHS Compliant							19.000 482.60mm		Top Mount, Extrusion					1.312 33.32mm	Adhesive
591202B03100G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black	15.24mm		0.600 15.24mm	RoHS Compliant				TO-220		12.7mm	0.500 12.70mm		Board Level				26.80°C/W	0.500 12.70mm	Clip and PC Pin	TO-220, TO-262	16.00°C/W @ 200 LFM	Black Anodized	1.0W @ 40°C
6030D(COPPER)G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Copper	Rectangular, Fins		2007	Active	Not Applicable		12.7mm		1.180 29.97mm	RoHS Compliant		No		TO-220		29.972mm	1.000 25.40mm		Board Level, Vertical				12.50°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	6.00°C/W @ 300 LFM	Tin	1.0W @ 20°C
6221BG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1		8 Weeks		Aluminum	Rectangular, Fins			Active	Not Applicable	Black			1.180 29.97mm	RoHS Compliant	Lead Free			TO-220		29.97mm	1.000 25.40mm		Board Level, Vertical					0.500 12.70mm	Bolt On and PC Pin	TO-220		Black Anodized
TV40G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1		8 Weeks	Screw	Aluminum	Rectangular, Fins		1999	Active	Not Applicable	Black	38mm		1.496 38.00mm	RoHS Compliant	Lead Free	No		TO-220	No SVHC	22mm	1.102 28.00mm		Board Level		4 mm	9.9 °C/W		0.866 22.00mm	Bolt On	TO-220		Black Anodized
375024B00032G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	8 Weeks		Aluminum	Square, Pin Fins	Bulk	2002	Active	Not Applicable	Black	40mm		1.575 40.00mm	RoHS Compliant	Lead Free	No		BGA	No SVHC	18mm	1.575 40.01mm		Top Mount	Metal			12.00°C/W	0.709 18.00mm	Thermal Tape, Adhesive (Included)	BGA	4.30°C/W @ 200 LFM	Black Anodized	2.0W @ 30°C
374024B00035G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	8 Weeks		Aluminum	Square, Pin Fins		2002	Active	Not Applicable	Black	23mm		0.906 23.01mm	RoHS Compliant	Lead Free	No		BGA	No SVHC	10mm	0.906 23.01mm		Top Mount				40.00°C/W	0.394 10.00mm	Thermal Tape, Adhesive (Included)	BGA	11.70°C/W @ 200 LFM	Black Anodized	1.0W @ 40°C
593202B03500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black	12.2mm		2.000 50.80mm	RoHS Compliant	Lead Free	No		TO-220		51mm	1.380 35.05mm		Board Level, Vertical				10.40°C/W	0.480 12.19mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 200 LFM	Black Anodized	6.0W @ 60°C
311505B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical		2007	Active	Not Applicable	Black		0.317 8.05mm ID 0.375 9.52mm OD		RoHS Compliant				TO-5	No SVHC	10.16mm			Board Level				90.00°C/W	0.400 10.16mm	Press Fit	TO-5	45.00°C/W @ 200 LFM	Black Anodized	1.0W @ 70°C
342942	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	6 Weeks	Push Pin	Copper	Square, Fins			Active	Not Applicable				1.732 44.00mm	RoHS Compliant							1.772 45.00mm		Top Mount				8.00°C/W	0.886 22.50mm	Push Pin	BGA	1.65°C/W @ 200 LFM	AavSHIELD 3C
6223BG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks	Bolt	Aluminum	Square, Fins		2007	Active	Not Applicable	Black			1.060 26.92mm	RoHS Compliant	Lead Free					31.75mm	1.060 26.92mm		Board Level				9.40°C/W	1.250 31.75mm	Bolt On	Bridge Rectifiers	3.00°C/W @ 400 LFM	Black Anodized	3.0W @ 30°C
580300B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	8 Weeks	Press Fit	Aluminum	Rectangular, Fins	Bulk	2003	Active	Not Applicable	Black			1.125 28.58mm	RoHS Compliant	Lead Free		18			14.12mm	0.700 17.78mm		Top Mount				39.00°C/W	0.556 14.12mm	Press Fit, Slide On	18-DIP	20.00°C/W @ 200 LFM	Black Anodized	2.0W @ 60°C
7173DG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Copper	Rectangular, Fins		2007	Active	Not Applicable		9.52mm		0.750 19.05mm	RoHS Compliant	Lead Free	No		TO-220	No SVHC	19.05mm	0.750 19.05mm	113.398093g	Board Level, Vertical	Copper			25.80°C/W	0.375 9.52mm	Bolt On and PC Pin	TO-220	10.00°C/W @ 200 LFM	Tin	1.5W @ 50°C
323005B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical		2007	Active	Not Applicable	Black	6.35mm	0.318 8.07mm ID 0.750 19.05mm OD	19.05mm	RoHS Compliant	Lead Free	No		TO-5	No SVHC	6.35mm	19.05mm		Board Level				56.00°C/W	0.250 6.35mm	Press Fit	TO-5	35.00°C/W @ 200 LFM	Black Anodized	1.4W @ 70°C
579704B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black			0.900 22.86mm	RoHS Compliant				TO-202		22.86mm	0.745 18.92mm		Board Level, Vertical				24.00°C/W	0.420 10.67mm	Clip	TO-202	11.00°C/W @ 400 LFM	Black Anodized	1.5W @ 40°C
542502D00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black	6.35mm		1.250 31.75mm	RoHS Compliant	Lead Free	No		TO-220	No SVHC	31.75mm	0.875 22.22mm		Board Level, Vertical				24.00°C/W	0.250 6.35mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 700 LFM	Tin	2.5W @ 60°C
513002B02500G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Box	2007	Active	Not Applicable	Black	12.7mm		1.000 25.40mm	RoHS Compliant	Lead Free	No		Radial	No SVHC	25.4mm	1.375 34.93mm		Board Level, Vertical				13.40°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 400 LFM	Black Anodized	2.0W @ 30°C
2240B ASSYG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1		9 Weeks						Active	Not Applicable					RoHS Compliant
575002D00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Screw		Rectangular, Fins		2007	Active	Not Applicable				1.180 29.97mm	RoHS Compliant				TO-220		29.97mm	1.000 25.40mm		Board Level, Vertical				13.60°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 400 LFM	Tin	1.0W @ 20°C
647064	Aavid, Thermal Division of Boyd Corporation	28.9725	Add to Cart Min: 1 Mult: 1				Copper	Rectangular, Fins			Active	Not Applicable				4.252 108.00mm	RoHS Compliant							3.071 78.00mm		Top Mount					2.519 64.00mm	Bolt On	Intel® Xeon® CPU
574102B03700G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin, Solder	Aluminum	Rectangular		2007	Active	Not Applicable	Black			0.750 19.05mm	RoHS Compliant	Lead Free			TO-220		19.05mm	0.860 21.84mm		Board Level, Vertical				23.20°C/W	0.395 10.03mm	Clip and PC Pin	TO-220	8.00°C/W @ 500 LFM	Black Anodized	2.0W @ 50°C
574902B03300G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin, Solder	Aluminum	Rectangular	Bulk	2007	Active	Not Applicable	Black	10.03mm		1.375 34.93mm	RoHS Compliant	Lead Free	No		TO-220		34.93mm	0.860 21.84mm		Board Level, Vertical				16.00°C/W	0.395 10.03mm	Clip and PC Pin	TO-220	6.00°C/W @ 400 LFM	Black Anodized	2.5W @ 40°C
6043BG	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular		2007	Active	Not Applicable	Black	20.32mm		0.800 20.32mm	RoHS Compliant	Lead Free	No			No SVHC	25mm	0.268 6.81mm		Board Level				23.00°C/W	1.000 25.40mm	Clip	TO-220	4.00°C/W @ 500 LFM	Black Anodized	1.5W @ 40°C
325705B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical		2007	Active	Not Applicable	Black		0.318 8.07mm ID 0.500 12.70mm OD	6.35mm	RoHS Compliant	Lead Free			TO-5	No SVHC	6.35mm			Board Level				60.00°C/W	0.250 6.35mm	Press Fit	TO-5	35.00°C/W @ 200 LFM	Black Anodized	1.0W @ 60°C
590102B03600G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins	Bulk	2007	Active	Not Applicable	Black	25.4mm		1.675 42.55mm	RoHS Compliant	Lead Free	No		TO-220	No SVHC	42.54mm	1.000 25.40mm	113.398093g	Board Level, Vertical				10.00°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-220	4.00°C/W @ 300 LFM	Black Anodized	2.5W @ 30°C
530402B00150G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black			1.750 44.45mm	RoHS Compliant	Lead Free			TO-220			0.750 19.05mm		Board Level, Vertical				6.30°C/W	1.750 44.45mm	Clip and Board Mounts	TO-220	2.00°C/W @ 400 LFM	Black Anodized	4.0W @ 30°C
563202D00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin	Anodized	Rectangular, Fins	Box	2007	Active	Not Applicable				2.000 50.80mm	RoHS Compliant	Lead Free			TO-220	No SVHC	50.8mm	1.380 35.05mm		Board Level, Vertical				9.40°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	5.00°C/W @ 200 LFM	Tin	2.0W @ 30°C
575502B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular, Fins		2007	Active	Not Applicable	Black			1.250 31.75mm	RoHS Compliant	Lead Free			TO-220		31.75mm	0.875 22.22mm		Board Level, Vertical				24.00°C/W	0.250 6.35mm	Bolt On and PC Pin	TO-220	6.00°C/W @ 400 LFM	Black Anodized	1.5W @ 40°C
530510B00000G	Aavid, Thermal Division of Boyd Corporation	0.0000	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins		2007	Active	Not Applicable		9.65mm		0.620 15.75mm	RoHS Compliant				SIP			0.845 21.46mm		Board Level				20.60°C/W	0.380 9.65mm	Clip	Multiwatt, SIP	6.00°C/W @ 400 LFM	Black Anodized	2.0W @ 50°C
