Heat Sinks

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Material	Shape	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Color	Depth	Diameter	Length	RoHS Status	Lead Free	Contact Plating	Radiation Hardening	Number of Pins	Package / Case	REACH SVHC	Height	Width	Weight	Type	Body Material	Power Dissipation	Natural Thermal Resistance	Thermal Resistance @ Natural	Height Off Base (Height of Fin)	Attachment Method	Package Cooled	Thermal Resistance @ Forced Air Flow	Material Finish	Power Dissipation @ Temperature Rise
577102B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rectangular, Fins	Bulk	2001		Active	Not Applicable	Black	9.52mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	9.52mm	0.520 13.21mm	113.398093g	Board Level				25.90°C/W	0.375 9.52mm	Bolt On	TO-220	12.00°C/W @ 200 LFM	Black Anodized	3.0W @ 80°C
573400D00010G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	PCB, Surface Mount	Copper	Rectangular, Fins	Tape & Reel (TR)	2007		Active	Not Applicable	Grey	12.7mm		0.500 12.70mm	RoHS Compliant	Lead Free	Tin	No		TO-268	No SVHC	10.2mm	1.220 30.99mm		Top Mount				14.00°C/W	0.401 10.20mm	SMD Pad	TO-268 (D3Pak)	4.00°C/W @ 600 LFM	Tin	1.0W @ 20°C
580100W00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Press Fit	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			0.562 14.27mm	RoHS Compliant				8			11.43mm	0.600 15.24mm		Top Mount				30.00°C/W	0.450 11.43mm	Press Fit, Slide On	8-DIP	8.00°C/W @ 500 LFM	Black Anodized	1.0W @ 30°C
566902B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Clip	Aluminum	Rectangular, Fins		2007		Active	Not Applicable				0.850 21.59mm	RoHS Compliant					TO-220			1.000 25.40mm		Board Level				18.80°C/W	0.500 12.70mm	Clip	TO-220, TO-262	9.00°C/W @ 200 LFM	Black Anodized	2.0W @ 40°C
323005B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical		2007		Active	Not Applicable	Black	6.35mm	0.318 8.07mm ID 0.750 19.05mm OD	19.05mm	RoHS Compliant	Lead Free		No		TO-5	No SVHC	6.35mm	19.05mm		Board Level				56.00°C/W	0.250 6.35mm	Press Fit	TO-5	35.00°C/W @ 200 LFM	Black Anodized	1.4W @ 70°C
PF750G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	8 Weeks	PCB, Through Hole	Aluminum	Rectangular		1999		Active	Not Applicable		11mm		0.866 22.00mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	19mm	0.433 11.00mm		Board Level, Vertical			20 °C/W		0.748 19.00mm	Clip and PC Pin	TO-220		Tin
6230DG (COPPER)	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks		Copper	Rectangular, Fins				Active	Not Applicable				1.180 29.97mm	RoHS Compliant								1.000 25.40mm		Board Level, Vertical				12.50°C/W	0.500 12.70mm	Bolt On and PC Pin	TO-220	6.00°C/W @ 300 LFM	Tin	1.0W @ 20°C
579402B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip	Aluminum	Rectangular, Fins	Bulk	2003		Active	Not Applicable	Black	19.05mm		0.750 19.05mm	RoHS Compliant	Lead Free		No		TO-220		11.18mm	0.980 24.89mm		Board Level	Aluminium			16.80°C/W	0.440 11.18mm	Clip	TO-220	6.00°C/W @ 500 LFM	Black Anodized	3.0W @ 50°C
575502B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			1.250 31.75mm	RoHS Compliant	Lead Free				TO-220		31.75mm	0.875 22.22mm		Board Level, Vertical				24.00°C/W	0.250 6.35mm	Bolt On and PC Pin	TO-220	6.00°C/W @ 400 LFM	Black Anodized	1.5W @ 40°C
551002B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rectangular, Fins	Bulk	2006		Active	Not Applicable	Black	36.83mm		1.450 36.83mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	19.99mm	1.006 25.55mm		Board Level				12.40°C/W	0.787 19.99mm	Bolt On	TO-220	4.00°C/W @ 300 LFM	Black Anodized	1.5W @ 20°C
M48059B011000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Angled Fins			Max Clip System™	Active	Not Applicable				0.590 15.00mm									0.866 22.00mm		Board Level, Vertical					1.516 38.50mm	Clip and PC Pin	TO-126, TO-220, TO-247		Black Anodized
2227B	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Press Fit	Aluminum	Cylindrical				Active	Not Applicable	Black		0.315 8.00mm ID 1.250 31.75mm OD		Non-RoHS Compliant	Lead Free				TO-5	Unknown	10.16mm			Board Level				21.00°C/W	0.400 10.16mm	Press Fit	TO-5	14.00°C/W @ 200 LFM	Black Anodized	1.8W @ 50°C
M49165B021000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Fins			Max Clip System™	Active	Not Applicable				1.650 41.91mm									0.866 22.00mm		Board Level, Vertical					1.260 32.00mm	Clip and PC Pin	TO-126, TO-220, TO-247		Black Anodized
529901B02100G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	50.8mm		2.000 50.80mm	RoHS Compliant	Lead Free		No		Radial		50.8mm	1.650 41.91mm		Board Level, Vertical				4.50°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-218	1.00°C/W @ 800 LFM	Black Anodized	12.0W @ 50°C
502403B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus	Bulk	2007		Active	Not Applicable	Black			1.630 41.40mm	RoHS Compliant	Lead Free						31.8mm	1.290 32.77mm		Board Level		12W			1.250 31.75mm	Bolt On			Black Anodized
573902B04000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	12.7mm		1.500 38.10mm	RoHS Compliant	Lead Free		No		TO-220	No SVHC	38.1mm	0.500 12.70mm		Board Level, Vertical				18.80°C/W	0.500 12.70mm	Clip and PC Pin	TO-220	7.00°C/W @ 200 LFM	Black Anodized	3.0W @ 60°C
530101B00100G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, Clip, Solder	Aluminum	Square, Fins		2007		Active	Not Applicable	Black	12.45mm		1.750 44.45mm	RoHS Compliant	Lead Free				TO-220		44.45mm	0.490 12.44mm		Board Level, Vertical				6.30°C/W	1.750 44.45mm	Bolt On and Board Mounts	TO-218, TO-247	1.50°C/W @ 400 LFM	Black Anodized	4.0W @ 30°C
574902B03700G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black	10.03mm		1.375 34.93mm	RoHS Compliant	Lead Free				TO-220	No SVHC	34.93mm	0.860 21.84mm		Board Level, Vertical				16.00°C/W	0.395 10.03mm	Clip and PC Pin	TO-220	6.00°C/W @ 400 LFM	Black Anodized	2.5W @ 40°C
500503B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt	Aluminum	Square, Pin Fins	Bulk	2003		Active	Not Applicable	Black			2.500 63.50mm	RoHS Compliant	Lead Free				TO-3		20.86mm	2.500 63.50mm		Board Level		14W		4.90°C/W	0.821 20.86mm	Bolt On	TO-3	2.00°C/W @ 500 LFM	Black Anodized	6.0W @ 40°C
501603B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus	Bulk	2003		Active	Not Applicable	Black	35.56mm		1.880 47.75mm	RoHS Compliant	Lead Free		No		TO-3	No SVHC	32mm	1.400 35.56mm	113.398093g	Board Level				7.80°C/W	1.250 31.75mm	Bolt On	TO-3	3.00°C/W @ 200 LFM	Black Anodized	4.0W @ 30°C
502203B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt	Aluminum	Rhombus	Bulk	2007		Active	Not Applicable	Black			1.630 41.40mm	RoHS Compliant	Lead Free						19.1mm	1.290 32.77mm		Board Level		6W			0.750 19.05mm	Bolt On			Black Anodized
569003B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PCB, Through Hole	Aluminum	Square, Pin Fins		2007		Active	Not Applicable	Black	46.48mm		1.830 46.48mm	RoHS Compliant	Lead Free				TO-3	No SVHC	33.27mm	1.830 46.48mm		Board Level				5.50°C/W	1.310 33.27mm	Bolt On	TO-3	1.50°C/W @ 500 LFM	Black Anodized	12.0W @ 60°C
780202F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular, Pin Fins		2016		Active	Not Applicable				49.500 1257.30mm	RoHS Compliant								1.181 30.00mm		Board Level, Vertical, Extrusion					1.850 47.00mm	Clip and PC Pin
581002B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks							Active	Not Applicable					RoHS Compliant	Lead Free
603402F00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks		Aluminum	Rectangular				Active	Not Applicable				48.000 1219.20mm	RoHS Compliant										Top Mount, Extrusion					1.312 33.32mm	Adhesive
2286B	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	9 Weeks	Adhesive	Aluminum	Square	Box			Active	Not Applicable				0.790 20.07mm	Non-RoHS Compliant	Lead Free				Radial			0.790 20.07mm		Board Level					0.155 3.94mm	Thermal Tape, Adhesive (Not Included)	BGA	20.00°C/W @ 200 LFM	Black Anodized	1.0W @ 40°C
577500B00000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Press Fit	Aluminum	Rectangular, Fins	Bulk	2003		Active	Not Applicable	Black	8.13mm		0.520 13.20mm	RoHS Compliant	Lead Free		No		TO-126	No SVHC	13.21mm	0.780 19.81mm		Board Level, Vertical				26.00°C/W	0.320 8.13mm	Press Fit, Slide On	TO-126	12.00°C/W @ 300 LFM	Black Anodized	1.0W @ 30°C
566902B04000G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Clip, PC Pin	Aluminum	Rectangular, Fins	Box	2007		Active	Not Applicable	Black	12.7mm		0.850 21.59mm	RoHS Compliant	Lead Free				TO-220		21.59mm	1.000 25.40mm		Board Level, Vertical				18.80°C/W	0.500 12.70mm	Clip and PC Pin	TO-220, TO-262	9.00°C/W @ 200 LFM	Black Anodized	2.0W @ 40°C
530001B02100G	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download	7 Weeks	Bolt, PC Pin, Solder	Aluminum	Rectangular, Fins		2007		Active	Not Applicable	Black			2.500 63.50mm	RoHS Compliant					Radial		63.5mm	1.650 41.91mm		Board Level, Vertical				8.00°C/W	1.000 25.40mm	Bolt On and PC Pin	TO-218	1.00°C/W @ 800 LFM	Black Anodized	20.0W @ 60°C
529902B00000	Aavid, Thermal Division of Boyd Corporation	RFQ Min: 1 Mult: 1	download		Bolt	Aluminum	Rectangular, Fins		2005		Active	Not Applicable				2.000 50.80mm	Non-RoHS Compliant							50.8mm	1.650 41.91mm		Board Level				4.50°C/W	1.000 25.40mm	Bolt On	TO-220	1.50°C/W @ 500 LFM	Black Anodized	6.0W @ 30°C
