Through Hole Resistors

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Packaging	Published	Series	Pbfree Code	Part Status	Moisture Sensitivity Level (MSL)	Number of Terminations	Termination	ECCN Code	Max Operating Temperature	Min Operating Temperature	ELV	Diameter	Length	RoHS Status	Lead Free	Contact Plating	Voltage - Rated	Radiation Hardening	Additional Feature	Package / Case	Height	Width	Resistance	Weight	Operating Temperature	Size / Dimension	Voltage - Rated DC	Height Seated (Max)	Packing Method	Power Rating	Lead Length	JESD-609 Code	Max Power Dissipation	Terminal Shape	Reference Standard	Composition	Feature	Tolerance	Construction	Temperature Coefficient	Resistor Type	Rated Power Dissipation (P)	Rated Temperature	Military Standard	Failure Rate	Supplier Device Package	Power Dissipation-Max	Power (Watts)	Number of Resistors
FLAX147R00F	Vishay Foil Resistors (Division of Vishay Precision Group)	RFQ Min: 1 Mult: 1		16 Weeks		Bulk		FLA		Active	Not Applicable	2														Radial			147Ohms		-25°C~155°C	0.220Lx0.087W 5.60mmx2.20mm		0.264 6.70mm								Metal Foil		±1%		±5ppm/°C						Radial Lead		0.125W 1/8W
RNR55H8872BSB14	Vishay Dale	RFQ Min: 1 Mult: 1	download	17 Weeks	Through Hole	Bulk		Military, MIL-PRF-55182/01, RNR55		Active	Not Applicable	2			175°C	-65°C		2.39mm	6.35mm	Non-RoHS Compliant	Contains Lead	Lead, Tin		No		Axial		2.39mm	88.7kOhms		-65°C~175°C	0.094Diax0.250L 2.39mmx6.35mm				125mW			125mW			Metal Film	Military, Moisture Resistant	±0.1%		±50ppm/°C				MIL-PRF-55182	S (0.001%)	Axial		0.125W 1/8W
HHV-50FT-52-16M	Yageo	RFQ Min: 1 Mult: 1	download			Tape & Box (TB)		HHV		Active	Not Applicable	2								ROHS3 Compliant						Axial			16MOhm		-55°C~155°C	0.130Diax0.354L 3.30mmx9.00mm										Metal Film	Flame Retardant Coating, High Voltage, Safety	±1%		±200ppm/°C								0.5W 1/2W
RTO020F40R00FTE3	Vishay Sfernice	RFQ Min: 1 Mult: 1	download	17 Weeks	Through Hole					Active	Not Applicable				155°C	-55°C			10.1mm	ROHS3 Compliant		Tin		No		TO-220	15mm		40Ohm							20W						Thick Film		1%		150 ppm/°C
RNR60C1153DSM76	Vishay	RFQ Min: 1 Mult: 1			Through Hole	Bulk												3.18mm	14.25mm	Non-RoHS Compliant		Lead, Tin		No		Conformal			115kOhm							250mW	38.1mm					Metal Film		0.5%		50 ppm/°C				MIL-PRF-55182
1879694-7	TE Connectivity	RFQ Min: 1 Mult: 1	download		Axial	Bulk			yes			2			155°C	-55°C	Compliant	2.5mm	7.1882mm	RoHS Compliant			350V		PRECISION				1.33kOhm	240.007063mg					TAPE	250mW				WIRE		Metal Film, Thin Film		0.1%		100 ppm/°C	FIXED RESISTOR		70°C				250mW		1
Y145318K0000F9L	Vishay Foil Resistors (Division of Vishay Precision Group)	RFQ Min: 1 Mult: 1				Bulk	2003	Z		Active	Not Applicable	2			175°C	-55°C			7.62mm	ROHS3 Compliant						Radial	8.5344mm	2.667mm	18kOhms		-55°C~125°C	0.300Lx0.105W 7.62mmx2.67mm		0.336 8.53mm					300mW			Metal Foil	Moisture Resistant, Non-Inductive	±1%		±0.2ppm/°C								0.6W
Y078529K9000T9L	Vishay Foil Resistors (Division of Vishay Precision Group)	RFQ Min: 1 Mult: 1				Bulk		S		Active	Not Applicable	2														Radial			29.9kOhms		-55°C~125°C	0.300Lx0.105W 7.62mmx2.67mm		0.336 8.53mm								Metal Foil	Moisture Resistant, Non-Inductive	±0.01%		±2ppm/°C								0.6W
Y144214K7000B0L	Vishay Foil Resistors (Division of Vishay Precision Group)	RFQ Min: 1 Mult: 1				Bulk	2010	RS92N		Active	Not Applicable	2			155°C	-55°C			7.493mm	Non-RoHS Compliant						Radial	8.001mm	2.4892mm	14.7kOhms		-55°C~125°C	0.295Lx0.098W 7.50mmx2.50mm		0.315 8.00mm					250mW			Metal Foil	Non-Inductive	±0.1%		±2ppm/°C								0.5W 1/2W
Y175995K0200T9L	Vishay Foil Resistors (Division of Vishay Precision Group)	RFQ Min: 1 Mult: 1				Bulk		HZ		Active	Not Applicable	4														Axial			95.02kOhms		-55°C~125°C	0.500Diax1.500L 12.70mmx38.10mm										Metal Foil	Non-Inductive	±0.01%		±0.2ppm/°C						Axial		2.5W
CW0013K800KE12	Vishay	RFQ Min: 1 Mult: 1			Through Hole										250°C	-65°C		2.39mm	11.1mm	RoHS Compliant		Tin				Ceramic			3.8kOhm							1W						Wirewound		10%		30 ppm/°C
NK424001JA22	Vishay	RFQ Min: 1 Mult: 1			Through Hole				yes			2		EAR99	155°C	-55°C		2.5mm	6.2mm	RoHS Compliant		Tin		No	PRECISION, RATED AC VOLTAGE: 350V	Conformal			24kOhm						Ammo Pack			e3		WIRE	CECC40101	Metal Film		5%	Tubular	100 ppm/°C	FIXED RESISTOR	0.5W	70°C
RN65D1982FB14	Vishay Dale	RFQ Min: 1 Mult: 1	download	13 Weeks		Bulk		Military, MIL-R-10509/2, RN65		Active	1 (Unlimited)	2							14.2748mm	Non-RoHS Compliant	Contains Lead					Axial		4.57mm	19.8kOhms		-65°C~175°C	0.180Diax0.562L 4.57mmx14.27mm				500mW			500mW			Metal Film	Flame Retardant Coating, Military, Moisture Resistant, Safety	±1%		±100ppm/°C						Axial		0.5W 1/2W
ROX07590M0FNLB	Vishay Dale	RFQ Min: 1 Mult: 1	download	13 Weeks		Bulk		ROX		Active	Not Applicable	2								ROHS3 Compliant						Axial			90MOhms		-55°C~180°C	0.310Diax0.800L 7.87mmx20.32mm										Metal Oxide Film	Flame Retardant Coating, High Voltage, Safety	±1%		±200ppm/°C						Axial		3W
RNR55C1291DSM76	Vishay	RFQ Min: 1 Mult: 1																											1.291kOhm							125mW	38.1mm
FMP100JT-52-910K	Yageo	RFQ Min: 1 Mult: 1	download			Tape & Box (TB)		FMP		Active	Not Applicable	2								ROHS3 Compliant						Axial			910kOhm		-55°C~155°C	0.094Diax0.248L 2.40mmx6.30mm										Metal Film	Flame Proof, Safety	±5%		±100ppm/°C								1W
ERG-2SJ823	Panasonic Electronic Components	RFQ Min: 1 Mult: 1	download	13 Weeks	Through Hole	Bulk	2011	ERG	yes	Not For New Designs	Not Applicable	2		EAR99				4mm		ROHS3 Compliant	Contains Lead	Tin			IEC60115-4, FLAME PROOF	Axial			82kOhm		-55°C~235°C	0.157Diax0.472L 4.00mmx12.00mm	350V			2W	30mm	e3	2W	WIRE		Metal Oxide Film	Flame Proof, Safety	±5%	Tubular	±350ppm/°C	FIXED RESISTOR	2W
RNR65E2342DPM7765	Vishay	RFQ Min: 1 Mult: 1		12 Weeks			2016													Non-RoHS Compliant									23.4kOhm							500mW	38.1mm
RNR75J4322FMBSL1	Vishay	RFQ Min: 1 Mult: 1																		Non-RoHS Compliant
RNR65E1600DMM77	Vishay	RFQ Min: 1 Mult: 1	download		Through Hole	Bulk									175°C	-65°C		4.78mm	19.81mm	RoHS Compliant		Lead, Tin		No		Conformal			160Ohm							500mW	38.1mm					Metal Film		0.5%		25 ppm/°C				MIL-PRF-55182
MFR200FRE52-237K	Yageo	RFQ Min: 1 Mult: 1	download			Tape & Reel (TR)		MFR		Active	Not Applicable	2								ROHS3 Compliant						Axial			237kOhm		-55°C~155°C	0.197Diax0.610L 5.00mmx15.50mm										Metal Film		±1%		±50ppm/°C								2W
FMP200FRE52-12R1	Yageo	RFQ Min: 1 Mult: 1	download			Tape & Reel (TR)		FMP		Active	Not Applicable	2								ROHS3 Compliant						Axial			12.1Ohm		-55°C~155°C	0.154Diax0.354L 3.90mmx9.00mm										Metal Film	Flame Proof, Safety	±1%		±50ppm/°C								2W
CMF554K1200FKEK	Vishay Dale	RFQ Min: 1 Mult: 1	download	29 Weeks	Through Hole	Bulk	2016	CMF		Active	1 (Unlimited)	2	Axial		175°C	-55°C		2.29mm	6.1mm	ROHS3 Compliant	Lead Free	Tin				Axial		2.29mm	4.12kOhms		-55°C~175°C	0.090Diax0.240L 2.29mmx6.10mm							500mW			Metal Film	Flame Retardant Coating, Moisture Resistant, Safety	±1%		±100ppm/°C				Not		Axial		0.5W 1/2W
RNC60H1001BPRSL	Vishay Dale	RFQ Min: 1 Mult: 1		17 Weeks		Tape & Reel (TR)		Military, MIL-PRF-55182/03, RNC60		Active	Not Applicable	2								Non-RoHS Compliant						Axial			1kOhms		-65°C~175°C	0.097Diax0.280L 2.46mmx7.11mm										Metal Film	Military, Moisture Resistant, Weldable	±0.1%		±50ppm/°C					P (0.1%)	Axial		0.25W 1/4W
RLR07C6040FPB14	Vishay Dale	RFQ Min: 1 Mult: 1	download	18 Weeks		Bulk		Military, MIL-PRF-39017/01, RLR07		Active	Not Applicable	2								Non-RoHS Compliant	Contains Lead					Axial			604Ohms		-65°C~150°C	0.090Diax0.250L 2.29mmx6.35mm				250mW						Metal Film	Military, Moisture Resistant, Weldable	±1%		±100ppm/°C					P (0.1%)	Axial		0.25W 1/4W
RNR60C1304FSRSL	Vishay	RFQ Min: 1 Mult: 1																	8.89mm	Non-RoHS Compliant	Contains Lead							2.46mm	1.3MOhm							250mW								1%
RNC55K2201FSB14	Vishay Dale	RFQ Min: 1 Mult: 1	download	11 Weeks		Bulk		Military, MIL-PRF-55182/01, RNC55		Active	Not Applicable	2							6.35mm	Non-RoHS Compliant	Contains Lead					Axial		2.39mm	2.2kOhms		-65°C~175°C	0.094Diax0.250L 2.39mmx6.35mm				125mW			125mW			Metal Film	Military, Moisture Resistant, Weldable	±1%		±100ppm/°C					S (0.001%)	Axial		0.125W 1/8W
RNR60C2492BRBSL1	Vishay	RFQ Min: 1 Mult: 1																		Non-RoHS Compliant	Contains Lead								24.9kOhm							250mW								0.1%
RNC60J2401FSB14	Vishay Dale	RFQ Min: 1 Mult: 1	download	11 Weeks		Bulk		Military, MIL-PRF-55182/03, RNC60		Active	Not Applicable	2							7.112mm	Non-RoHS Compliant	Contains Lead					Axial		2.46mm	2.4kOhms		-65°C~175°C	0.097Diax0.280L 2.46mmx7.11mm				250mW			250mW			Metal Film	Military, Moisture Resistant, Weldable	±1%		±25ppm/°C					S (0.001%)	Axial		0.25W 1/4W
RWR71S2051FSB12	Vishay Dale	RFQ Min: 1 Mult: 1	download	15 Weeks	Through Hole	Bulk	2017	Military, MIL-PRF-39007, RWR71S		Active	1 (Unlimited)	2			250°C	-65°C		4.75mm	20.6248mm	Non-RoHS Compliant	Contains Lead	Lead, Tin				Axial		4.75mm	2.05kOhms		-55°C~250°C	0.187Diax0.812L 4.75mmx20.62mm				2W	38.1mm		2W			Wirewound	Military, Moisture Resistant	±1%		±20ppm/°C				MIL-PRF-39007	S (0.001%)	Axial		2W
