AC Fans

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Material	Housing Material	Packaging	Published	Series	Part Status	Moisture Sensitivity Level (MSL)	Termination	Max Operating Temperature	Min Operating Temperature	Color	Depth	Operating Supply Voltage	Diameter	Length	RoHS Status	Lead Free	Voltage - Rated	Current Rating	Package / Case	REACH SVHC	Height	Width	Approval Agency	Thickness	Weight	Operating Temperature	Size / Dimension	Voltage Range	Ratings	Voltage - Rated AC	Ingress Protection	Power Rating	Max Power Dissipation	Feature	Cable Length	Current Rating (Amps)	Lifetime @ Temp	Life (Hours)	Power Consumption	Air Flow	Power (Watts)	Material - Frame	Material - Blade	RPM	Bearing Type	Fan Type	Noise	Static Pressure	Thermal Support Device Type
109S488	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1							San Ace 120	Active	Not Applicable	3 Wire Leads								ROHS3 Compliant		200VAC						CE, PSE, TUV, UL		0.863lb 391.45g	14~140°F -10°C~60°C	Square - 120mm Lx120mm H							Locked Rotor Protection, Speed Sensor (Tach)		0.070A	25000 Hrs @ 60°C			81.3 CFM (2.28m3/min)	12.00W	Aluminum	Plastic	2900 RPM		Tubeaxial	41.0 dB(A)	0.216 in H2O (53.9 Pa)
ASEN60512	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1	download					2006		Obsolete	1 (Unlimited)	2 Wire Leads										115VAC									14~140°F -10°C~60°C	Square - 60mm Lx60mm H									0.060A				9.3 CFM (0.260m3/min)	4.00W	Aluminum	Plastic	2600 RPM	Ball	Tubeaxial	29.0 dB(A)
GTB036PUD25R N1	Delta Electronics	RFQ Min: 1 Mult: 1	download	19 Weeks				2012	GTB	Active	1 (Unlimited)	Terminal Block								ROHS3 Compliant		400VAC						cUL, TUV, UL		23lbs 10.4kg	-13~140°F -25°C~60°C	Round - 360.2mm Dia	380V~480VAC			IP54 - Dust Protected, Water Resistant			PWM Control, Speed Sensor (Tach)		1.75A	60000 Hrs @ 40°C			3054.0 CFM (85.51m3/min)	648W	Aluminum		2200 RPM	Ball	Motorized Impellers	80.0 dB(A)	3.330 in H2O (829.5 Pa)
109S304	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1	download	16 Weeks		Aluminium	Bulk	2014	San Ace 172	Active	Not Applicable	2 Terminals	60°C	-30°C		172mm		172mm	172mm	ROHS3 Compliant		115VAC	290mA	Axial	Unknown	150mm	51.00mm	CE, CSA, PSE, TUV, UL		2.3lbs 1kg	-22~140°F -30°C~60°C	Rectangular/Rounded - 172mm Lx150mm H					25W				0.540A	25000 Hrs @ 60°C			226.1 CFM (6.33m3/min)	25.00W	Aluminum	Plastic	3500 RPM	Ball	Tubeaxial	56.0 dB(A)	0.787 in H2O (196.0 Pa)
ASEN804529	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1	download					2006		Obsolete	1 (Unlimited)	2 Terminals	140°C	14°C						RoHS Compliant		115VAC					38.00mm				14~140°F -10°C~60°C	Square - 80mm Lx80mm H						7W							32.1 CFM (0.899m3/min)	7.00W	Aluminum	Plastic	3200 RPM	Ball	Tubeaxial	38.0 dB(A)
AFF-3020G-120VAC	Altech Corporation	RFQ Min: 1 Mult: 1		3 Weeks						Active	1 (Unlimited)									ROHS3 Compliant
UF15AC12-BTHR	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks				2005	UF15AC	Active	1 (Unlimited)	2 Terminals								RoHS Compliant		115VAC					38.00mm	CE, cUL, TUV, UL		1.6lbs 725.7g	-40~158°F -40°C~70°C	Rectangular/Rounded - 172mm Lx150mm H							Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)		0.230A				212.0 CFM (5.94m3/min)	28.00W	Aluminum	Polybutylene Terephthalate (PBT)	3400 RPM	Ball	Tubeaxial	58.0 dB(A)	0.750 in H2O (186.8 Pa)
OA172LFGH111T	Orion Fans	RFQ Min: 1 Mult: 1	download	16 Weeks				2017	OA172LFGH	Active	Not Applicable	2 Terminals or 2 Wire Leads								ROHS3 Compliant		115VAC						cURus, TUV			-40~158°F -40°C~70°C	Square - 207mm Lx207mm H	80V~130VAC						Kit			60000 Hrs @ 40°C			235.0 CFM (6.58m3/min)	35.00W	Aluminum	Polybutylene Terephthalate (PBT)	3200 RPM	Ball	Tubeaxial	52.0 dB	0.700 in H2O (174.4 Pa)
ASEN902529	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1	download					2006		Obsolete	1 (Unlimited)	2 Terminals										115VAC						CSA, UL			14~140°F -10°C~60°C	Square - 92.5mm Lx92.5mm H									0.130A				35.0 CFM (0.980m3/min)	10.00W	Aluminum	Plastic	3100 RPM	Ball	Tubeaxial	39.0 dB(A)
109S429UL	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1							San Ace 120	Active	Not Applicable	3 Wire Leads								ROHS3 Compliant		100VAC						CE, PSE, TUV, UL		1.3lbs 589.7g	14~140°F -10°C~60°C	Square - 120mm Lx120mm H							Locked Rotor Protection, Speed Sensor (Tach)		0.160A	25000 Hrs @ 60°C			83.0 CFM (2.32m3/min)	12.00W	Aluminum	Plastic	2700 RPM		Tubeaxial	40.0 dB(A)	0.197 in H2O (49.0 Pa)
17000654A	Comair Rotron	RFQ Min: 1 Mult: 1	download	18 Weeks				2017		Active	1 (Unlimited)	Terminal Block								ROHS3 Compliant		230VAC					80.00mm	CE, cUL, UL		4.1lbs 1.9kg	-4~158°F -20°C~70°C	Square - 225mm Lx225mm H	207V~253VAC						Auto Restart, Electronic Commutation, Locked Rotor Protection		0.300A	Varies Based on Temperature			532.0 CFM (14.90m3/min)	46.00W	Magnesium Alloy	Magnesium Alloy	2800 RPM	Ball	Tubeaxial	65.0 dB(A)	1.000 in H2O (249.1 Pa)
ASEN902579	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1						2006		Obsolete	1 (Unlimited)	2 Terminals										240VAC						CE, UR			14~140°F -10°C~60°C	Square - 92mm Lx92mm H									0.065A				35.0 CFM (0.980m3/min)	10.00W	Aluminum	Plastic, Fiberglass Reinforced	3100 RPM	Ball	Tubeaxial	39.0 dB(A)	0.244 in H2O (60.8 Pa)
19020189A	Comair Rotron	RFQ Min: 1 Mult: 1	download	18 Weeks				2012	Caravel AC	Active	1 (Unlimited)	2 Terminals								ROHS3 Compliant	Lead Free	115VAC	500mA	Axial				CE, cUL, UL		4.4lbs 2kg	-22~140°F -30°C~60°C	Round - 254mm Dia						61W			0.5A	54000 Hrs @ 40°C			550.0 CFM (15.40m3/min)	61.0W	Aluminum	Plastic	1650 RPM	Ball	Tubeaxial	49.2 dB(A)	0.331 in H2O (82.4 Pa)
ASEN10412	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1	download		Aluminium, PVC	Aluminium		2006		Obsolete	1 (Unlimited)	2 Wire Leads	140°C	14°C	Black					RoHS Compliant		115VAC	250mA			120mm	38.00mm			1.2lbs 544.3g	14~140°F -10°C~60°C	Square - 119mm Lx119mm H					15.5W	14.5W		300mm					103.4 CFM (2.90m3/min)	14.50W	Aluminum	Plastic	2900 RPM	Ball	Tubeaxial	41.0 dB(A)
ASEN10211	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1						2006		Obsolete	1 (Unlimited)	2 Wire Leads	140°C	14°C						RoHS Compliant		100VAC	180mA				25.50mm			0.794lb 360.15g	14~140°F -10°C~60°C	Square - 119mm Lx119mm H						11W			0.180A				70.6 CFM (1.98m3/min)	11.00W	Aluminum	Plastic	2700 RPM	Ball	Tubeaxial	38.0 dB(A)
LPC135A12-BTHR	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	21 Weeks				2017	LPC135A	Obsolete	1 (Unlimited)	2 Terminals								Non-RoHS Compliant		115VAC					38.00mm				-40~158°F -40°C~70°C		90V~264VAC						Electronic Commutation (EC)								Magnesium	Plastic		Ball	Tubeaxial
R87FA3A85HP	Omron Electronics Inc-EMC Div	RFQ Min: 1 Mult: 1		60 Weeks					R87F	Active	1 (Unlimited)									RoHS Compliant		115VAC						CSA, UL													0.097A				32.1 CFM (0.899m3/min)	8.00W			3250 RPM	Ball	Tubeaxial	43.0 dB
OA254LFGH221TXC	Orion Fans	RFQ Min: 1 Mult: 1	download	16 Weeks					OA254LFGH XC	Active	Not Applicable	2 Terminals or 2 Wire Leads								ROHS3 Compliant		230VAC						cURus, TUV			-4~158°F -20°C~70°C	Square - 322.7mm Lx322.7mm H	160V~260VAC						Kit			60000 Hrs @ 40°C			850.0 CFM (23.80m3/min)	75.0W	Aluminum	Polybutylene Terephthalate (PBT)	2700 RPM	Ball	Tubeaxial	69.0 dB	0.780 in H2O (194.3 Pa)
4590ZW	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks					4000Z	Active	1 (Unlimited)	2 Wire Leads								ROHS3 Compliant		115/230VAC								1.2lbs 544.3g		Square - 119mm Lx119mm H													68.0 CFM (1.90m3/min)	12.0W	Metal		1900 RPM	Sintec	Tubeaxial	30.0 dB		AC FAN
UF250APA12-H1C2F	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks				2014	UF250APA-F	Active	1 (Unlimited)	2 Wire Leads								RoHS Compliant		115VAC					131.0mm	CE, cUL, TUV, UL		7.2lbs 3.3kg	-40~122°F -40°C~50°C	Round - 259mm Dia							Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)		2.10A				681.0 CFM (19.07m3/min)	240W	Aluminum	Polyamide (PA), Nylon	2700 RPM	Ball	Motorized Impellers	72.0 dB(A)	3.100 in H2O (772.2 Pa)
ASEN80211	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1						2006		Obsolete	1 (Unlimited)	2 Wire Leads										100VAC									14~140°F -10°C~60°C	Square - 80mm Lx80mm H									0.080A				30.3 CFM (0.848m3/min)	5.00W	Aluminum	Plastic	2750 RPM	Ball	Tubeaxial	33.0 dB(A)
FDA2-17255QBKW3D	Qualtek	RFQ Min: 1 Mult: 1		16 Weeks					HPLC, FDA2-17255	Active	1 (Unlimited)	2 Wire Leads								ROHS3 Compliant		230VAC	120mA					CE, cURus, TUV		1.8lbs 816.5g	-4~158°F -20°C~70°C	Rectangular/Rounded - 172mm Lx151mm H		IP56, Water Resistant		IP56M - Dust Protected, Water Resistant		27W			0.120A	50000 Hrs @ 25°C			240.0 CFM (6.72m3/min)	27.00W	Aluminum	Plastic	3100 RPM	Ball	Tubeaxial	61.0 dB(A)	0.531 in H2O (132.3 Pa)
FAA1-08025QBMW31	Qualtek	RFQ Min: 1 Mult: 1		21 Weeks		Aluminium		2012	FAA1-08025	Active	1 (Unlimited)	2 Wire Leads					230V			ROHS3 Compliant	Lead Free	230VAC	55mA	Axial		80mm		CE, cURus, TUV		0.463lb 210.01g	14~158°F -10°C~70°C	Square - 80mm Lx80mm H					14.2W	11W			0.055A				19.0 CFM (0.532m3/min)	11.00W	Aluminum	Plastic	2500 RPM	Ball	Tubeaxial	24.0 dB(A)	0.118 in H2O (29.4 Pa)	AC FAN
OA225AN-22-1TB18	Orion Fans	RFQ Min: 1 Mult: 1	download	15 Weeks		Aluminium	Box	2010	OA225	Active	1 (Unlimited)	Terminal Block								ROHS3 Compliant	Lead Free	230VAC	350mA	Axial		225mm		cURus, TUV			-40~140°F -40°C~60°C	Round - 225mm Dia	200V~240VAC	IP55, Water Resistant		IP55 - Dust Protected, Water Resistant	80W	80W			0.350A	40000 Hrs @ 40°C	40000 hours		600.0 CFM (16.80m3/min)	80.0W	Aluminum	Metal	2800 RPM	Ball	Tubeaxial	61.0 dB	0.670 in H2O (166.9 Pa)
AFF-5010G-120VAC	Altech Corporation	RFQ Min: 1 Mult: 1		3 Weeks				2014		Active	1 (Unlimited)									ROHS3 Compliant
CF4113LBL-000U-A99	Sunon Fans	RFQ Min: 1 Mult: 1	download	14 Weeks				2016	CF	Active	Not Applicable	2 Wire Leads								ROHS3 Compliant		110/230VAC						CE, CUR, TUV, UL		0.595lb 269.89g	-13~158°F -25°C~70°C	Square - 120mm Lx120mm H	90V~265VAC					1.8W	Auto Restart, Electronic Commutation (EC), Dual Voltage		0.022/0.037A				64.3 CFM (1.80m3/min)	1.80W	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT)	2000 RPM	Ball	Tubeaxial	31.4 dB(A)	0.170 in H2O (42.3 Pa)
4656ZWU	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks	Metal				4000ZU	Active	1 (Unlimited)	2 Wire Leads				38mm	230V			ROHS3 Compliant		230VAC		Axial		119mm		CCC, CE, CSA, UL, VDE	38mm	539.77492g	-40~176°F -40°C~80°C	Square - 119mm Lx119mm H		Dust Tight, IP65, Water Resistant	230V	IP65 - Dust Tight, Water Resistant	17W	17W				37500 Hrs @ 40°C		19W	105.9 CFM (2.97m3/min)	17.00W			3100 RPM	Ball	Tubeaxial	42.0 dB(A)	0.321 in H2O (80.0 Pa)
R3G500-AG25-64F	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download						Green Tech R3G500	Active	1 (Unlimited)									ROHS3 Compliant		380V~480VAC	3.3A					UL		50lbs 22.7kg	-13~140°F -25°C~60°C	Round - 505mm Dia	380V~480VAC	IP54, Water Resistant		IP54 - Dust Protected, Water Resistant		2.5kW	Electronic Commutation (EC), Thermal Overload Protector (TOP)						6450 CFM (180.6m3/min)	2500W	Aluminum		1700 RPM		Motorized Impellers, 3 Phase
FDA2-17255QBHT4D-L	Qualtek	RFQ Min: 1 Mult: 1		16 Weeks				2014	HPLC, FDA2-17255	Active	1 (Unlimited)	2 Terminals								ROHS3 Compliant		230VAC	120mA					CE, cURus, TUV		1.8lbs 816.5g	-4~158°F -20°C~70°C	Rectangular/Rounded - 172mm Lx151mm H		IP56, Water Resistant		IP56M - Dust Protected, Water Resistant		27W			0.120A	100000 Hrs @ 25°C			240.0 CFM (6.72m3/min)	27.00W	Aluminum	Steel	3100 RPM	Ball	Tubeaxial	61.0 dB(A)	0.531 in H2O (132.3 Pa)
FDA2-17238QBHT3F-L	Qualtek	RFQ Min: 1 Mult: 1		16 Weeks				2014	HPLC, FDA2-17238	Active	1 (Unlimited)	2 Terminals	158°C	-4°C						ROHS3 Compliant		230VAC	120mA				38.50mm	CE, cURus, TUV		1.8lbs 816.5g	-4~158°F -20°C~70°C	Rectangular/Rounded - 172mm Lx151mm H		IP54, Water Resistant		IP54 - Dust Protected, Water Resistant		27W			0.120A	100000 Hrs @ 25°C			240.0 CFM (6.72m3/min)	27.00W	Aluminum	Plastic	3100 RPM	Ball	Tubeaxial	59.0 dB(A)	0.571 in H2O (142.2 Pa)
