AC Fans

Name	Manufacturer	Quantity	Datasheet	Factory Lead Time	Mount	Material	Housing Material	Packaging	Published	Series	Pbfree Code	Part Status	Moisture Sensitivity Level (MSL)	Termination	Max Operating Temperature	Min Operating Temperature	Color	Depth	Operating Supply Voltage	Diameter	Length	RoHS Status	Lead Free	Voltage - Rated	Current Rating	Radiation Hardening	Additional Feature	Package / Case	REACH SVHC	Frequency	Height	Width	Approval Agency	Outside Diameter	Thickness	Weight	Operating Temperature	Size / Dimension	Voltage Range	Ratings	Voltage - Rated AC	Ingress Protection	Power Rating	Max Power Dissipation	Feature	Cable Length	Current Rating (Amps)	Lifetime @ Temp	Life (Hours)	Power Consumption	Air Flow	Power (Watts)	Material - Frame	Material - Blade	RPM	Bearing Type	Fan Type	Noise	Static Pressure	Thermal Support Device Type
OA172SAPL-22-1TBIP55	Orion Fans	RFQ Min: 1 Mult: 1	download	15 Weeks			Aluminium		2013	OA172SAPL		Active	1 (Unlimited)	2 Terminals								ROHS3 Compliant		230VAC				Axial			150mm		cURus, TUV				-4~176°F -20°C~80°C	Rectangular/Rounded - 172mm Lx150mm H	160V~260VAC	IP55, Water Resistant		IP55 - Dust Protected, Water Resistant	42W	28W				60000 Hrs @ 40°C	60000 hours		228.0 CFM (6.38m3/min)	28.00W	Aluminum	Polybutylene Terephthalate (PBT)	3400 RPM	Ball	Tubeaxial	58.0 dB	0.870 in H2O (216.7 Pa)
109S484-20	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1	download	16 Weeks				Bulk	2016	San Ace 120		Active	Not Applicable	3 Wire Leads								ROHS3 Compliant		115VAC								25.00mm	CE, PSE, TUV, UL			0.86lb 390.09g	14~140°F -10°C~60°C	Square - 119mm Lx119mm H							Alarm		0.120A	25000 Hrs @ 60°C			81.3 CFM (2.28m3/min)	12.00W	Aluminum	Plastic	2900 RPM	Ball	Tubeaxial	41.0 dB(A)	0.216 in H2O (53.9 Pa)
LPH60B99-BWHR-PC	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	14 Weeks						LPH60B99		Active	1 (Unlimited)	2 Wire Leads								RoHS Compliant		100V~240VAC												0.154lb 69.85g		Square - 60mm Lx60mm H	90V~264VAC			IP55 - Dust Protected, Water Resistant			Auto Restart, Electronic Commutation (EC), Parylene Coating		0.060A				17.0 CFM (0.476m3/min)	2.30W	Plastic		4500 RPM	Ball	Tubeaxial	35.0 dB(A)	0.240 in H2O (59.8 Pa)
W2S130-AB03-19	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks			Plastic			W2S130		Active	Not Applicable	2 Wire Leads with Splice Terminals								RoHS Compliant		230VAC				Axial					CE				-13~140°F -25°C~60°C	Round - 172mm Dia				IP44			Thermal Overload Protector (TOP)		0.250A				325 CFM	39.00W	Aluminum	Steel	3250 RPM	Ball	Tubeaxial
OA109AP-11-1TB(SF)	Orion Fans	RFQ Min: 1 Mult: 1	download	15 Weeks			Aluminium		2013	OA109		Active	1 (Unlimited)	2 Terminals								ROHS3 Compliant	Lead Free	115VAC	160mA			Axial			120mm		cURus				-4~158°F -20°C~70°C	Square - 119.5mm Lx119.5mm H					12W	12W	Salt Fog Rated		0.160A	40000 Hrs @ 40°C	40000 hours		106.0 CFM (2.97m3/min)	12.00W	Aluminum	Polybutylene Terephthalate (PBT)	3100 RPM	Ball	Tubeaxial	46.0 dB	0.320 in H2O (79.7 Pa)
R4E310-AQ19-10	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	8 Weeks	Flanges		Aluminium			R4E310		Active	Not Applicable	4 Wire Leads with Splice Terminals						318mm		RoHS Compliant		277VAC		No				60Hz	139mm		CE, CSA, UL				140°F 60°C	Round - 318mm Dia				IP44	210W		Capacitor, Thermal Overload Protector (TOP)		0.770A							Aluminum	1670 RPM	Ball	Motorized Impellers			AC FAN
109S474UL-20	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1	download	16 Weeks			Aluminium	Bulk		San Ace 120		Active	Not Applicable	3 Wire Leads					115V		120mm	ROHS3 Compliant		115VAC							120mm	38.00mm	CE, PSE, TUV, UL			1.3lbs 589.7g	14~140°F -10°C~60°C	Square - 119mm Lx119mm H					18W		Alarm		0.180A	25000 Hrs @ 60°C			102.4 CFM (2.87m3/min)	16.00W	Aluminum	Plastic	3100 RPM	Ball	Tubeaxial	45.0 dB(A)	0.276 in H2O (68.7 Pa)
3610PS-10T-B20-B00	NMB Technologies Corporation	RFQ Min: 1 Mult: 1	download	18 Weeks					2009	PS		Active	1 (Unlimited)	2 Terminals				92.5mm				RoHS Compliant		100VAC	85mA	No		Axial			92.5mm		CE, CSA, TUV, UL, VDE			0.661lb 299.82g	14~158°F -10°C~70°C	Square - 92.5mm Lx92.5mm H						6W			0.085A	50000 Hrs @ 25°C			28.0 CFM (0.784m3/min)	6.00W	Aluminum	Polycarbonate (PC), Fiberglass Reinforced	2500 RPM	Ball	Tubeaxial	35.0 dB	0.157 in H2O (39.2 Pa)
109S081	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1						Bulk		San Ace 120		Active	Not Applicable	2 Wire Leads								ROHS3 Compliant		100VAC									CE, CSA, PSE, TUV, UL			0.816lb 370.13g	-22~140°F -30°C~60°C	Square - 120mm Lx120mm H							Locked Rotor Protection		0.110A	25000 Hrs @ 60°C			63.6 CFM (1.78m3/min)	8.50W	Aluminum	Plastic	2350 RPM		Tubeaxial	35.0 dB(A)	0.106 in H2O (26.4 Pa)	AC FAN
UF250APA23-H1C2F	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2014	UF250APA-F		Active	1 (Unlimited)	2 Wire Leads								RoHS Compliant		230VAC								131.0mm	CE, cUL, TUV, UL			7.2lbs 3.3kg	-40~122°F -40°C~50°C	Round - 259mm Dia							Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)		1.00A				681.0 CFM (19.07m3/min)	240W	Aluminum	Polyamide (PA), Nylon	2700 RPM	Ball	Motorized Impellers	72.0 dB(A)	3.100 in H2O (772.2 Pa)
A4D300-AS34-10	ebm-papst Inc.	RFQ Min: 1 Mult: 1								A4D300		Active	Not Applicable	6 Wire Leads								Non-RoHS Compliant		480VAC				Axial					CCC, CE, CSA, UL				-13~122°F -25°C~50°C	Round - 300mm Dia				IP44			Thermal Overload Protector (TOP)		0.160A					105W		Plastic	1510 RPM	Ball	Tubeaxial, 3 Phase		0.321 in H2O (80.0 Pa)
4600XP	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks	Flanges	Metal				4600X		Active	1 (Unlimited)	2 Terminals	60°C			119mm	115V			ROHS3 Compliant	Lead Free	115VAC			APPROVALS: VDE	Axial		5.06kHz	119mm		CSA; UL		38mm	1.2lbs 544.3g		Square - 119mm Lx119mm H			115V		18W	18W						18W	106.0 CFM (2.97m3/min)	18.00W				Sintec	Tubeaxial	50.0 dB(A)		AC FAN
ASEN10214	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1							2006			Obsolete	1 (Unlimited)	2 Wire Leads	140°C	14°C						RoHS Compliant		200VAC	90mA							25.50mm				0.794lb 360.15g	14~140°F -10°C~60°C	Square - 119mm Lx119mm H						11W			0.090A				71.5 CFM (2.00m3/min)	11.00W	Aluminum	Plastic	2700 RPM	Ball	Tubeaxial	38.0 dB(A)
UF250BMB12-H1C2A-B1	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2007	UF250BMB-H1		Active	1 (Unlimited)	3 Terminals								RoHS Compliant		115VAC								80.00mm	CE, cUL, TUV, UL			6.1lbs 2.8kg	-4~158°F -20°C~70°C	Square - 280mm Lx280mm H							Permanent Split Capacitor Motor, Speed Sensor (Tach), Thermal Overload Protector (TOP)		1.50A				1130.0 CFM (31.64m3/min)	148W	Metal	Metal	2700 RPM	Ball	Tubeaxial	70.0 dB(A)	0.780 in H2O (194.3 Pa)
R2E190-AO74-91	ebm-papst Inc.	RFQ Min: 1 Mult: 1		8 Weeks						R2E190		Active	Not Applicable	Wire Leads					115V			RoHS Compliant																Round - 190mm Dia					75W		Capacitor, Thermal Overload Protector (TOP)						365 CFM			Polyamide (PA), Nylon, Fiberglass Reinforced		Ball	Motorized Impellers
ASEN10416	Panasonic Industrial Automation Sales	RFQ Min: 1 Mult: 1	download			Aluminium, PVC	Aluminium		2006			Obsolete	1 (Unlimited)	2 Wire Leads	140°C	14°C	Black					RoHS Compliant		230VAC	100mA						120mm	38.00mm				1.2lbs 544.3g	14~140°F -10°C~60°C	Square - 119mm Lx119mm H					15W	14W		300mm	0.100A				103.4 CFM (2.90m3/min)	14.00W	Aluminum	Plastic	2900 RPM	Ball	Tubeaxial	41.0 dB(A)
LPC135A23-BTHR	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	21 Weeks					2017	LPC135A		Obsolete	1 (Unlimited)	2 Terminals								Non-RoHS Compliant		230VAC								38.00mm					-40~158°F -40°C~70°C		90V~264VAC						Electronic Commutation (EC)								Magnesium	Plastic		Ball	Tubeaxial
R3G500-AG34-63F	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download							Green Tech R3G500		Active	1 (Unlimited)		140°C	-13°C						ROHS3 Compliant		220V~240VAC	7.8A							319.0mm	UL			50lbs 22.7kg	-13~131°F -25°C~55°C	Round - 505mm Dia	200V~240VAC	IP54, Water Resistant		IP54 - Dust Protected, Water Resistant		2.7kW	Electronic Commutation (EC), Thermal Overload Protector (TOP)		7.8A				6450 CFM (180.6m3/min)	2700W	Aluminum	Aluminum	1700 RPM		Motorized Impellers, 3 Phase
UF220APA23-H2C2A	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2014	UF220APA		Active	1 (Unlimited)	2 Wire Leads								RoHS Compliant		230VAC								71.00mm	CE, cUL, TUV, UL			3.2lbs 1.5kg	-40~122°F -40°C~50°C	Round - 223mm Dia							Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)		0.390A				530.0 CFM (14.84m3/min)	117W	Aluminum	Polyamide (PA), Nylon	2650 RPM	Ball	Motorized Impellers	70.0 dB(A)	1.700 in H2O (423.5 Pa)
FDA2-28080QBHK4D	Qualtek	RFQ Min: 1 Mult: 1		16 Weeks					2014	HPLC, FDA2-28080		Active	1 (Unlimited)	Terminal Block								ROHS3 Compliant		230VAC	630mA								CE, cURus, TUV			6.7lbs 3kg	-4~158°F -20°C~70°C	Square - 320mm Lx320mm H		IP56, Water Resistant		IP56M - Dust Protected, Water Resistant		138W			0.630A	50000 Hrs @ 25°C			1150.0 CFM (32.20m3/min)		Aluminum	Steel	2900 RPM	Ball	Tubeaxial	73.0 dB(A)	0.807 in H2O (201.0 Pa)
5915PC-24T-B30-S00	NMB Technologies Corporation	RFQ Min: 1 Mult: 1	download	18 Weeks					2009	PC		Active	1 (Unlimited)	2 Terminals				172mm				RoHS Compliant		240VAC	200mA	No		Axial			38mm		CE, CSA, UL, VDE			2lbs 907.2g	14~158°F -10°C~70°C	Rectangular/Rounded - 172mm Lx150mm H					39W	39W			0.200A	50000 Hrs @ 25°C			187.1 CFM (5.24m3/min)	39.00W	Aluminum	Polycarbonate (PC), Fiberglass Reinforced	3150 RPM	Ball	Tubeaxial	53.0 dB	0.655 in H2O (163.2 Pa)
AC8300H	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks	Flanges	PVC	Polymer			AC8300H	yes	Active	1 (Unlimited)	2 Wire Leads			Black	80mm	265V			ROHS3 Compliant		115VAC				Axial	No SVHC	5.06kHz	80mm		CCC, CE, CSA, UL, VDE			0.717lb 325.22g	-4~167°F -20°C~75°C	Square - 80mm Lx80mm H	85V~265VAC	IP54, Water Resistant		IP54 - Dust Protected, Water Resistant	7.5W	8.3W				55000 Hrs @ 40°C		7.5W	46.9 CFM (1.31m3/min)	8.30W	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	Polyamide (PA), Nylon, Fiberglass Reinforced	5000 RPM	Ball	Tubeaxial	48.0 dB(A)		AC FAN
OA172EC-11-1TBIP68A	Orion Fans	RFQ Min: 1 Mult: 1	download	16 Weeks						OA172EC		Active	Not Applicable	2 Terminals								ROHS3 Compliant		115VAC									ATEX, CE, cURus, UR			1.543lb 700.0g	-4~158°F -20°C~70°C	Rectangular/Rounded - 172mm Lx150mm H	103V~127VAC			IP68 - Dust Tight, Waterproof			Electronic Commutation (EC), Thermal Overload Protector (TOP)		0.230A	50000 Hrs @ 40°C			220.0 CFM (6.16m3/min)	15.00W	Aluminum	Polybutylene Terephthalate (PBT)	3000 RPM	Ball	Tubeaxial	57.0 dB(A)	0.620 in H2O (154.4 Pa)
UF15PC23-BWHR	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2005	UF15PC		Active	1 (Unlimited)	2 Wire Leads								RoHS Compliant		230VAC								51.00mm	CE, cUL, TUV, UL			1.8lbs 816.5g	-40~158°F -40°C~70°C	Rectangular/Rounded - 172mm Lx150mm H							Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)		0.120A				226.0 CFM (6.33m3/min)	31.00W	Aluminum	Polybutylene Terephthalate (PBT)	3400 RPM	Ball	Tubeaxial	58.0 dB(A)	0.790 in H2O (196.8 Pa)
UF13A12-BWHR	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2005	UF13A		Active	1 (Unlimited)	2 Wire Leads								RoHS Compliant		115VAC								38.00mm	CE, cUL, TUV, UL			1.2lbs 544.3g	-40~158°F -40°C~70°C	Square - 127mm Lx127mm H									0.160A				120.0 CFM (3.36m3/min)	12.00W	Aluminum	Polybutylene Terephthalate (PBT)	3000 RPM	Ball	Tubeaxial	50.0 dB(A)	0.140 in H2O (34.9 Pa)
FAA1-12038QHAW31-A	Qualtek	RFQ Min: 1 Mult: 1		20 Weeks					2013	FAA1-12038		Active	1 (Unlimited)	2 Wire Leads								ROHS3 Compliant		230VAC	40mA			Axial			119.5mm		CE, cURus, TUV			1.2lbs 544.3g	14~158°F -10°C~70°C	Square - 119.5mm Lx119.5mm H						7.7W			0.040A				53.5 CFM (1.50m3/min)	7.70W	Aluminum	Plastic	1700 RPM	Hydrodynamic	Tubeaxial	30.5 dB(A)	0.060 in H2O (14.9 Pa)
W2E143-AA15-01	ebm-papst Inc.	RFQ Min: 1 Mult: 1	download	20 Weeks	Flanges	Aluminium	Aluminium			W2E143		Active	1 (Unlimited)	2 Terminals	176°C	-40°C		171.5mm	115V	172mm	171.5mm	ROHS3 Compliant		115VAC	250mA	No		Axial	No SVHC	5.06kHz	172mm	51.00mm	CCC, CE, CSA, GOST, UL, VDE	172 mm		2.1lbs 952.5g	-40~176°F -40°C~80°C	Round - 171.5mm Dia			115V		26W	26W			0.230A			26W	258.9 CFM (7.25m3/min)	26.00W	Aluminum	Steel	3300 RPM	Ball	Tubeaxial	60.0 dB(A)
109S033	Sanyo Denki America Inc.	RFQ Min: 1 Mult: 1	download	16 Weeks				Bulk	2016	San Ace 80		Active	Not Applicable	2 Terminals								ROHS3 Compliant		115VAC								25.00mm	CE, CSA, PSE, TUV, UL			0.595lb 269.89g	-22~140°F -30°C~60°C	Square - 80mm Lx80mm H									0.080A	25000 Hrs @ 60°C			22.3 CFM (0.624m3/min)	7.00W	Aluminum	Plastic	2700 RPM	Ball	Tubeaxial	30.0 dB(A)	0.114 in H2O (28.4 Pa)
UF318AAA23-H1C4A-L32	Mechatronics Fan Group	RFQ Min: 1 Mult: 1	download	12 Weeks					2015	UF318AAA		Active	Not Applicable	2 Wire Leads								RoHS Compliant		230VAC									CE, cUL, TUV, UL			8.3lbs 3.8kg	-4~158°F -20°C~70°C	Round - 318mm Dia							Permanent Split Capacitor Motor, Thermal Overload Protector (TOP)		0.700A				1165.0 CFM (32.62m3/min)	160W	Steel		1580 RPM	Ball	Motorized Impellers	66.0 dB(A)	1.600 in H2O (398.6 Pa)
OA172SAN-11-2WB	Orion Fans	RFQ Min: 1 Mult: 1	download	15 Weeks			Aluminium		2001	OA172S		Active	1 (Unlimited)	2 Wire Leads								ROHS3 Compliant		115VAC				Axial			150mm		cURus, TUV				-40~158°F -40°C~70°C	Rectangular/Rounded - 172mm Lx150mm H	80V~130VAC				20W	20W				60000 Hrs @ 40°C			170.0 CFM (4.76m3/min)	20.00W	Aluminum	Polybutylene Terephthalate (PBT)	2400 RPM	Ball	Tubeaxial	42.0 dB	0.490 in H2O (122.1 Pa)
